Computer Cover
1.
Prepare the computer for disassembly
CAUTION:
the power cord is disconnected from the electrical outlet.
2.
Press in on the tabs (1) on each side of the computer to release the latches that secure the cover
to the computer chassis.
3.
Slide the computer cover forward (2) about 1.3 cm (1/2 inch), then lift it off the chassis.
Figure 7-3
To install the computer cover, reverse the removal procedure.
64
Chapter 7 Removal and Replacement Procedures — Small Form Factor (SFF) Chassis
Before removing the computer cover, ensure that the computer is turned off and that
Removing the Computer Cover
(Preparation for Disassembly on page
61).
ENWW
