HP Rp5700 - Point of Sale System Reference Manual page 83

10. Press the latch release on the front of the power supply (1), and then raise the power supply to the
upright position (2).
Figure 7-11
11. Open both latches of the memory module socket (1), and insert the memory module into the
socket (2).
NOTE:
For maximum performance, populate equally as possible.
12. Push the module down into the socket, ensuring that the module is fully inserted and properly
seated. Make sure the latches are in the closed position (3).
Figure 7-12
13. Repeat steps 10 and 11 to install any additional modules.
To reassemble the computer, reverse the removal procedure.
ENWW
Releasing and Rotating the Power Supply
A memory module can be installed with the tab on the memory socket.
Installing a DIMM
Memory 73
