Remove the Bluetooth module (3) from the base enclosure.
3.
Reverse this procedure to install the Bluetooth module.

Front USB board

Description
Front USB board
Before removing the front USB board, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Remove the following components:
5.
Hard drive (see
a.
Optical drive (see
b.
Keyboard (see
c.
Hinge cover (see
d.
Rear cover (see
e.
Top cover (see
f.
Battery on page 38).
Hard drive on page 45)
Optical drive on page
Keyboard on page 54)
Hinge cover on page
Rear cover on page 57)
Top cover on page 59)
52)
56)
Component replacement procedures
Spare part number
452314-001
