Summary of Contents for Yamaha Sound Edge

  • Page 2 INTRODUCTION Thank you for purchasing the Yamaha Sound Edge—a high quality sound card with on-board musical instrument sounds and digital effects bundled with a number of software applications with the power to turn your IBM PC/AT compatible personal computer into a high fidelity multimedia center. Sound Edge gives you enormous multimedia potential that will add an entirely new dimension to your computer, including direct access to the wide world of music, stereo digital sound recording and playback, and much more.
  • Page 3 SPECIAL NOTICES The Sound Edge software and this owner’s manual are the exclusive copyrights of Yamaha Corporation. Copying of the software or reproduction of this manual in whole or in part by any means is expressly forbidden without the written consent of the manufacturer. Use of the software and this manual is governed by the license agreement which the purchaser fully agrees to upon breaking the seal of the software packaging.

  • Page 4: Main Features

    MAIN FEATURES AWM WAVE TABLE Advanced Wave Memory (AWM) tone generation system. Maximum 24-note polyphony permits simultaneous use of many different instrument voices. General MIDI (GM) compatibility. Can play standard MIDI file (SMF) format files. The SampleEdit, one of the Yamaha applications, lets you play your own recorded WAV digital audio files on a musical scale, and with a sequencer program to give you greater access to the wide world of music.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Special Notices & Precautions ........... I Main Features ................II Sound Edge Package Contents & Minimum System Requirements .... 2 S e t u p Connections ................4 Sound Edge Setup ............ 5 Sound Edge 1. Names and Functions ........5 A p p l i c a t i o n S o f t w a r e 2.

  • Page 6: Package Contents & Minimum System Requirements

    PACKAGE CONTENTS & MINIMUM SYSTEM REQUIREMENTS PACKAGE CONTENTS The Sound Edge package includes the items listed below, so before beginning, please take a moment to make sure you have everything you need. (If something is missing, please contact your authorized Yamaha dealer.) Sound card Floppy Disk x 4: Install Disk 1, 2, 3, 4 Microphone (2-lead condenser type)
  • Page 7 OTHERS Additional hardware as listed below will permit maximum enjoyment of the Sound Edge. CD-ROM Drive Sound Edge supports three types of ISA CD-ROM interfaces to save an expansion slot: Panasonic, Sony and Mitsumi. JOYSTICK You can connect a joystick to the MIDI/JOYSTICK connector for use with specified applications. (Supports an IBM PC/AT series Dsub-15 pin connector.) POWER SPEAKERS You can enjoy powerful and dynamic stereo sound by connecting power speakers and other...

  • Page 8: Connections

    CONNECTIONS MAKING CONNECTIONS The following diagram shows how to connect the various devices. CD-ROM Drive Audio Out PC/AT Computer Sound Edge Sound Card Joystick External MIDI synthesizer, etc. LINE IN MIDI/JOYSTICK OUTPUT MIDI OUT Dsub -15 pin Mini Jack Yamaha MIDI Adaptor Cable MDC-01 Audio Cable Stereo Mini Jack Portable Cassette Recorder...

  • Page 9: Sound Edge Setup

    Sound Edge Setup SOUND EDGE SETUP 1. NAMES AND FUNCTIONS (Default) CN5 CN1 CN6 CN3 OUTPUT jack: Stereo mini plug type jack outputs standard line-level stereo signals. Allows connection to power speakers or the inputs of a recording mixer and other audio devices including headphones.
  • Page 10 Sound Edge Setup : Indicates the Jumper is set to short (ON) position. : Indicates the Jumper is set to open (OFF) position. Ground Pin R Output Pin L Output Pin Ground Pin L Input Pin Ground Pin R Input Pin MIC TYPE: Lets you switch back and forth between two types of amplifier configurations depending on the type of microphone connected.

  • Page 11: Sound Card Installation

    Sound Edge Setup 2. SOUND CARD INSTALLATION The sound card fits into an expansion slot in your computer. ¢You cannot use more than one sound card. Please remove any other sound card which may already be installed before attempting to install the Sound Edge. 1.
  • Page 12 Sound Edge Setup 4. Carefully remove the sound card from the anti-static bag. ¢Before touching the sound card, first touch a metal surface to discharge any static electricity in your body; such static electricity can cause serious damage to your Sound Edge. Also do not touch the inside surfaces of your sound card in order to prevent possible interference with or damage to the circuitry.

  • Page 13: Software Installation

    Sound Edge Setup 3. SOFTWARE INSTALLATION Installing the Software The four floppy disks included in the Sound Edge package—Install Disk 1, 2, 3, 4—contain both Yamaha and Voyetra application software programs. ¢To ensure proper installation, before installing the software, be sure to exit all applications which may be active (including Windows) and reboot the MS-DOS.
  • Page 14 Sound Edge Setup When Install Disk 1 is verified, the following screen will appear. £If you want to quit the installation process, press the <ESC> key. 4. Press any key on your computer keyboard. The Installer screen is replaced by the Name screen. Select the drive onto which you want to install the Sound Edge software.
  • Page 15 Sound Edge Setup 6. Verify the directory name and press the <ENTER> key. The Directory Name screen is replaced by the following screen. 7. Verify the drive and directory name—if correct press <Y>; if incorrect press <N>. Pressing <N> will return you to the beginning of the installation procedure. Pressing <Y>...
  • Page 16 Sound Edge Setup 10. Press either <Y> or <N> on your keyboard. For Windows users, press <Y> to proceed to Installing for Windows , below. (For DOS users, press <N> to finish the installation.) This completes the software installation for DOS. £If you only wish to use these programs on the DOS, proceed to M16INIT Setup Procedure , page 66.
  • Page 17 FAST_DAMP=0 IOAddress=530 aux=mad16c.drv PCM_MIX=0 SingleModeDMA=No midi2=opldld.drv FM_MIX=0 CONTROL.INI The Sound Edge software program will automatically add the following lines to the CONTROL.INI file. [drivers.desc] m16midi.drv=Opti External MIDI Driver mad16c.drv=YAMAHA Audio Device Driver opldld.drv=YAMAHA OPL4 Driver [Userinstallable.drivers] midi1=m16midi.drv wave=mad16c.drv midi2=opldld.drv...

  • Page 18: About The Driver And Midi Mapper

    When you click to open the driver in the Windows Main group, you can see three different drivers: OPTi External MIDI Driver, YAMAHA Audio Device Driver and YAMAHA OPL4 Driver. ¢If you removed a previous sound card before installing the Sound Edge, delete any accompanying driver programs.
  • Page 19 Sound Edge Setup Setting Up MIDI Mapper MIDI Mapper lets you select either the internal MIDI sound card (OPL4) or an external MIDI device in order to play MIDI data. 1. Double click the [MIDI Mapper] icon in the Control Panel window. The MIDI Mapper window appears.

  • Page 20: About The Midi Interface For Dos

    Sound Edge Setup About the MIDI Interface for DOS The Sound Edge MIDI Interface lets you use the internal AWM synthesizer to play the sounds of GM compatible DOS games and sequencers. When the Sound Edge software installation is done properly, the following lines will automatically be added to CONFIG.SYS and AUTOEXEC.BAT: To CONFIG.SYS: DEVICE=C:\YAMAHA\OPL4TSR.SYS (Device Driver on the DOS system)

  • Page 21: Sound Edge Application Software

    Sound Edge Application Software SOUND EDGE APPLICATION SOFTWARE Sound Edge application programs can be used with Windows or DOS. Running the Sound Edge with Windows allows you to take full advantage of the complete multimedia capabilities of the software and hardware. Hello...

  • Page 22: Windows Applications

    Sound Edge Application Software WINDOWS APPLICATIONS The Yamaha Sound Edge has an on-board DSP (effects processor) that can perform various types of effects on AWM wave table sounds, CD-ROM audio playback, and signals input by a microphone. In Windows the Yamaha applications EffectGear, VoiceMorph and EffectEdit are used to control the function of the DSP chip.

  • Page 23: Names And Functions

    Sound Edge Application Software Names and Functions 1 ABOUT button: Click this button to see information about this version of EffectGear. 2 PULL DOWN MENU button: Click this button to open the list of effect types. You can also open the list of effect types by double clicking on the [Effect] display box.

  • Page 24: Operation

    Sound Edge Application Software Operation 1. To display the effect type list, click the [Pull Down Menu] button or double click on the [Effect] display box. 2. Select an effect type from the list which appears. £There are 32 different types of DSP effects to choose from, including everything from “Hall” and “Room” reverbs to unique “Alien Voice”, “Devil”...

  • Page 25: Voicemorph

    Sound Edge Application Software VoiceMorph VoiceMorph lets you apply unique effects to line-level and microphone signals that completely alter the original sound. You can also apply VoiceMorph effects to AWM wave table or FM instrument sounds when playing back a MIDI song file with the sequencer program. Startup Procedure Double click on the [VoiceMorph] icon and the VoiceMorph application will start.

  • Page 26: Operation

    Sound Edge Application Software Control Gain/LFO Setup: Lets you open the Control Panel to set up the output (“Gain”) level or the LFO settings. Help Contents: Lets you open the Online Help. About VoiceMorph: Lets you see information about this version of VoiceMorph. 2 Type: There are 16 different types of voice change programs which will appear in the window.

  • Page 27: Effectedit

    Sound Edge Application Software EffectEdit Compared to EffectGear and VoiceMorph, EffectEdit gives you more control over the internal DSP, since it can be used to edit and reconfigure the DSP. The Sound Edge DSP has four different types of effects programs and provides three different kinds of sound input—from the AWM wave table and the FM tone generator, from the stereo analog input, and from the mono input (through a Microphone), and analog stereo output.

  • Page 28: Startup Procedure

    Sound Edge Application Software Startup Procedure Double click on the [EffectEdit] icon and the EffectEdit application will start. Names and Functions The EffectEdit window has a pull down menu and block diagram which is configured with various controllers. Pull Down Menus File New: Lets you open a new DSP block diagram by choosing from Type0~3 to edit the effect program...
  • Page 29 Sound Edge Application Software Memory Lets you determine the signal processing memory allocation for each controller of the DSP in the block diagram, including Mic Echo, Key Control and Surround 1 and 2. Key Control’s DSP memory allocation and Type1’s DSP memory layout allocation are fixed. When you select [Memory] the Memory Layout setup dialog box appears.

  • Page 30: Block Diagram

    Sound Edge Application Software Block Diagram When you start EffectEdit the Type0 window appears. The block diagram let’s you edit effects graphically. In this block diagram, the sound signal is input through the mixer from the left side, passes through the controllers such as Mic Echo and Key Control, then goes through a mixer before being output on the right side.
  • Page 31 Sound Edge Application Software Type1: The Audio/MIDI input goes through Voice Cancel and the MIC IN input goes through the Key Control pitch shifter, then passes through the Surround delay. Since Key Control is connected to MIC IN, you can use it to produce special sound effects like those in VoiceMorph, as well as chorus effects.

  • Page 32: Controller And Mixer Setup

    Sound Edge Application Software Controller and Mixer Setup There are basically six types of controllers and mixers. Click on either a [controller] or [mixer] box to open the setup dialog box. Effect Program Overview (Type0) VOICE CANCEL KEY CONTROL SURROUND I N P U INPUT MIXER MIC ECHO...
  • Page 33 Sound Edge Application Software Mixers There are three types of mixers: one for input, one for output, and one for remix. Input Mixer The Input Mixer is located on the left side of the dialog box. The input channels are configured by MIDI L/R, Audio L/R, Audio L as mono and Mic inputs.

  • Page 34: Output Mixer

    Sound Edge Application Software Output Mixer The Output Mixer is located on the right side of the block diagram. The analog L/R output signal will be output from two separate mixers. Click the [Output Mixer] box to open the Output Mixer setup dialog box. 1 Sign/Level/Value: Same as for the Input Mixer;...

  • Page 35: Mic Echo

    Sound Edge Application Software Mic Echo Mic Echo is available in Type0. You can use Mic Echo to delay the input signal or filter the input signal to modify frequency characteristics. Click the [Mic Echo] box to open the Mic Echo setup dialog box. 1 - 1 2 - 2 1 IIR Filter (Infinite Impulse Response Filter)
  • Page 36 Sound Edge Application Software 2 Delay Design Box Delay is like a simultaneous echo effect. You can set the time, volume, and number of delays. Sign Volume Sign Time On the right side in the Delay Design box you can set the delay by clicking and dragging the [red point] up and down to determine the time and volume of delay feedback.
  • Page 37 Sound Edge Application Software Surround With Surround you can apply precise delay effects to the input signal. Click the [Surround] box and the Surround setup dialog box appears. 1 Input: Same as Sign/Level/Value in the Input Mixer, above; however, in this case it adjusts the signal level input to the Surround.

  • Page 38: Operation

    Sound Edge Application Software Operation This section describes basic operations and provides a tutorial showing how to create an effect program. We’ll make an effect by using a microphone input sound split into two voices, one an octave higher (right channel) and one an octave lower (left channel) than the other, and adding an echo type effect to them.
  • Page 39 Sound Edge Application Software 3. Click and drag the [Mic input level] fader upward and set it to a value of about 80. Double click the [Control Menu] box in the upper left corner to close the Mixer box. 4. Click the 5th (from the top) Input Mixer box to open the Input Mixer setup dialog box, then click and drag the [Mic input level] fader also up to 80.
  • Page 40 Sound Edge Application Software Apply Echo Now let’s apply an echo effect. You’ll need to increase the Surround output level on the right Output Mixer to audition the amount of echo while modifying the setting. 9. Click the [Output Mixer] box to open the Output Mixer setup dialog box, then click and drag the [Surround] fader to increase the Surround output level to maximum position.
  • Page 41 Sound Edge Application Software 13. Drag the [black point] to the right as shown in the illustration on the previous page. When you move the black point to a new location in the upper (R), the time location of the black point in the lower (L) will adjust accordingly.

  • Page 42: Sampleedit

    Sound Edge Application Software SampleEdit You can use SampleEdit to read wave files, edit the waveforms, and play them as melodies. You can use the SampleEdit downloading feature to use wave data files recorded by other application software (such as WinDAT, or MIDI Orchestrator Plus that are included with Sound Edge) as tone generators for sequencers (such as the MIDI Orchestrator Plus) in the same way as the Sound Edge synthesizer (AWM/ FM).

  • Page 43: Waveform Editing Window

    Sound Edge Application Software Files Usable with SampleEdit You can use three types of files with SampleEdit: .WAV, .OPL, and .OMP. Of these three, .WAV and .OPL files can be read for waveform editing. After waveform editing, the files are saved as .OPL files.

  • Page 44: Startup Procedure

    Sound Edge Application Software Startup Procedure To start SampleEdit, double click the [SampleEdit] icon in the YAMAHA Sound Edge group. Names and Functions Toolbar: Lets you execute various features just by clicking on buttons. The toolbar can be displayed when necessary. To display or erase the toolbar, use the [View] menu. Work area: Lets you edit wave files in the Waveform editing window, and lets you open the Mapping window.
  • Page 45 Sound Edge Application Software Copy button: Copies the selected area to the clipboard, but does not affect the selected area in the window. Paste button: Pastes the contents of the clipboard into the specified position. The waveform area following the specified position is moved to the right to accommodate the new data. Reverse button: Reverses the selected area.
  • Page 46 Sound Edge Application Software Setting the YAMAHA OPL4 Driver To use wave data (read by SampleEdit) to produce sound (for example by using the MIDI soft keyboard or a sequencer), you must select RAM as the sound generator in the OPL4 Drive Panel window.
  • Page 47 Sound Edge Application Software Menus Available menus depend on the currently active window. When the waveform editing window is active Menus When the MIDI Soft Keyboard window is active File Menu When the Mapping window is active New OMP: Creates a new .OMP file. Displays the new Mapping window. £For details on the Mapping window, see page 58.
  • Page 48 Sound Edge Application Software Keyboard Menu Displays the MIDI Soft Keyboard window. You can sound the wave data being edited or a synthesizer (AWM/FM) by clicking on the keyboard. £You can play the sound of the tone generator selected in the OPL4 Drive Panel window. The OPL4 Drive Panel window is displayed by clicking on the button in the toolbar.

  • Page 49: Midi Channel

    Sound Edge Application Software £The names of the instrument voices displayed here conform to the GM instrument voices (GM System Level 1). £For details on the program change numbers of wave data, see page 48. Parameters: Sets parameters such as the MIDI channel for the wave data being used. 1 MIDI Channel: Sets the MIDI send channel.

  • Page 50: View Menu

    Sound Edge Application Software View Menu Toolbar: To display the toolbar, select [Toolbar]. Status Bar: To display the status bar, select [Status Bar]. Edit Menu The [Edit] menu is available only when the waveform editing window is active. Other than the command [Select All], all the commands in the [Edit] menu are also available in the toolbar.

  • Page 51: One Play

    Sound Edge Application Software Effect Menu The [Effect] menu is available only when the waveform editing window is active. All the commands in the [Effect] menu are also available in the toolbar. Reverse: Reverses the selected area. The beginning and end of the selected waveform area are reversed, so that the sound plays backwards.

  • Page 52: Zoom Menu

    Sound Edge Application Software Zoom Menu The [Zoom] menu is available only when the waveform editing window is active. All the commands in the [Zoom] menu are also available in the toolbar. Zoom In: Magnifies the display of the selected area. Zoom Out: Returns the display to the size before the zoom in.
  • Page 53 Sound Edge Application Software Level Maximum 3 Decay Level Minimum Time 2 Decay 1 Rate 1 Attack Rate 4 Decay 2 Rate 5 Release Rate Key On Key Off 1 Attack Rate: Sets the attack time—that is, the time it takes for a sound to reach the maximum level after a key is pressed.

  • Page 54: Window Menu

    Sound Edge Application Software 11 Vibrato Depth: Sets the depth of the vibrato effect. Valid values are from 0 to 7 (maximum). The initial value is 0. 12 Tremolo Depth: Sets the depth of the tremolo effect. Valid values are from 0 to 7 (maximum). The initial value is 0.
  • Page 56 Sound Edge Application Software Reading Wave Files You can read wave files recorded by other application software and files of previously created material, and you can edit the waveforms. SampleEdit can handle the following three types of files, but only files that have the .WAV or .OPL file extension can be read and used for waveform editing.
  • Page 57 Sound Edge Application Software Editing in the Waveform Editing Window You can use SampleEdit to edit a waveform in the same way you would use word-processing software to edit a document: for example, you can use the commands [Copy], [Cut], or [Paste]. First you select the waveform area that you want to edit, then you execute various commands to affect that area.

  • Page 58: Editing Effects

    Sound Edge Application Software Editing Commands You can use the [Edit] pulldown menu to simply cut undesired parts from a waveform, or to insert some part into a different location. 1. To select the waveform area that you want to edit, drag the mouse pointer through the desired area.

  • Page 59: Zoom Function

    Sound Edge Application Software Zoom Function You can use the [Zoom] menu to magnify the waveform to make it easier to see, or to quickly display the entire waveform. 1. Select the waveform area that you want to magnify. To select the area, drag the mouse pointer through the desired area.
  • Page 60 Sound Edge Application Software Setting the Loop Point The loop function enables you to repeatedly play a part of a waveform between two points. You can use the loop function to produce sound as a musical instrument by continuously playing short wave data. You can set the start point at any desired location.
  • Page 61 Sound Edge Application Software The MIDI Soft Keyboard The MIDI soft keyboard simulates a MIDI keyboard controller. As with an ordinary MIDI keyboard, you need to set the MIDI send channels before using the MIDI soft keyboard. The MIDI soft keyboard is convenient because it enables you to easily play the keyboard in order to audition sounds (for example, when editing wave data) without connecting an external MIDI keyboard.
  • Page 62 Sound Edge Application Software Saving Wave Files After editing in the waveform editing window, you can save the file in the .OPL format. £Using SampleEdit, you can assign .OPL files to the program change numbers in the Mapping window, and download the wave files to the RAM, and use them for sequencer playback.
  • Page 63 Sound Edge Application Software Opening a .OMP File Downloading requires a .OMP file. You can make a new .OMP file or read an existing .OMP file. £The .OMP file consists of the listed .OPL files. So to make a .OMP file, first create various types of .OPL files in the waveform editing window, then save them on the hard disk beforehand.
  • Page 64 Sound Edge Application Software Assigning OPL Files to Patch Numbers In the Mapping window, you can assign up to 128 .OPL files to patch numbers as far as free RAM is available and download them. 1. Click the OPL File name box that corresponds to the number of the patch you want to assign.

  • Page 65: Sample File List

    Sound Edge Application Software About Sample Files The accompanying sample files which are automatically placed in the \YAMAHA\DATA directory, contain various types of .OPL and .OMP files. You can select them by opening the File Selection dialog box using the file [Open] command from the [File] menu, and designating the \YAMAHA\DATA directory.

  • Page 66: Error Messages

    Sound Edge Application Software Error Messages An unexpected error occurred while OPL4 WAVE RAM overflow! reading [pathname]. Displayed when not enough RAM memory is available Displayed when the file with the specified pathname during an attempt to do one of the following: Play cannot be read.

  • Page 67: Dos Applications

    Sound Edge Application Software DOS APPLICATIONS You can use the KPCON and KPLOAD commands to control the DSP from DOS. * The symbol “_” indicates a space in a command. KPCON KPCON lets you control the DSP from the DOS command line. (KPCON’s function is similar to EffectEdit in Windows.) Startup Procedure Start KPCON in the YAMAHA directory.
  • Page 68 Sound Edge Application Software Operation The following key operation will show the syntax for commands that allow you to control the DSP effects. [KEY OPERATION] KPCON_/__________ ( long underline indicates command name ) Control the KPCON with the following commands. COMMAND CONTENTS q u i e t...

  • Page 69: Kpload

    Sound Edge Application Software KPLOAD The KPLOAD command lets you use the effects with DOS, which functions similar to EffectGear in Windows. You can use KPLOAD with KPCON for precise setups. Startup Procedure Access the KP directory by typing the following command on the DOS command line. [KEY OPERATION] CD_\YAMAHA Operation...

  • Page 70: Appendix

    Appendix APPENDIX Configuration Setup Yamaha Sound Edge is installed with certain default settings; however, some computers may not execute the functions properly. Therefore, you may need to adjust your computer’s configuration using the Opti M16INIT program. This will allow you to set the configuration of the Digital Sound Controller Opti 82C928 built into the Sound Edge’s sound card.
  • Page 71 Appendix Configuration Setup [KEY OPERATION] Select [Configure], then press <ENTER>. The Configuration setup window appears. [KEY OPERATION] Use the cursor keys to select an item, then press <ENTER> or <SPACE BAR> to execute the selection. Press the <ESC> key to exit the Configuration window. ITEM CONTENTS DEFAULT...
  • Page 72 Appendix [OK] Applies the modified settings [Load] Loads the configuration file [Save] Saves the configuration file [Volume] Sets the sound card’s volume [Cancel] Cancels the modified settings When you select [Volume], the VOLUME SETTINGS dialog box setup screen appears. You can assign different output level settings independently for each input source. Use the <←><→>...

  • Page 73: Sound Test

    Appendix Sound Test If the configuration setup is completed correctly, you should be able to hear the sound test. [KEY OPERATION] Select [Sound Test], then press <ENTER>. If you cannot hear any sound in the Sound Test, return to the Configuration screen and configure the setup once again.

  • Page 74: Cd-Rom Installation

    Appendix CD-ROM INSTALLATION The Yamaha Sound Edge SW20 has a CD-ROM connector and includes an interface which lets you set up a CD-ROM player without a CD-ROM interface card. Compatible CD-ROMs The following types of CD-ROMs can be used. Panasonic/Creative: CR 562B/563 Sony: CDU 31A/33A Mitsumi: CRMC LU005S, CRMC FX001/001D CD-ROM Connection...
  • Page 75 Appendix CD-ROM Setup Driver Setup You can use the floppy disks included with your CD-ROM player to set up the driver. (You will need to set up MSCDEX.EXE and an ISA CD-ROM Device Driver.) Refer to your CD-ROM owner’s manual for the proper procedure for setting up the driver. ¢If you have been using SoundBlaster and have a Panasonic/Creative CD-ROM player, you must delete /SBP:220 from the CD-ROM Device Driver Setup Line in the CONFIG.SYS file.

  • Page 76: Troubleshooting

    AudioStation and other products, and you must therefore use Single Mode DMA. In this case, select [YAMAHA Audio Device Driver] in the [Driver] (Control Panel), and click [Setup] to open the YAMAHA Sound Driver Setup window. Click [Advanced Settings] to open the Advanced Settings window. In...

  • Page 77: Patch (Instrument) List (Gm Map)

    Appendix PATCH (Instrument) LIST (GM VOICE MAP) Category No. Patch Name Category No. Patch Name Piano Acoustic Grand Piano Reed Soprano Sax Bright Acoustic Piano Alto Sax Electric Grand Piano Tenor Sax Honky-tonk Piano Baritone Sax Electric Piano 1 Oboe Electric Piano 2 English Horn Harpsichord...

  • Page 78: Drum Key Assign List

    Appendix DRUM KEY ASSIGN LIST Program No. Key Off Alternate Standard Room Rock Electric Analog Jazz Brush Classic YAMAHA Voyetra B -1 Click L Click R Brush Tap Brush Swirl L Brush Slap Brush Swirl H Reverse Cymbal Reverse Cymbal Snare Roll Castanet Hi Q...

  • Page 79: Specifications

    Appendix SPECIFICATIONS Minimum System Requirements Computer (PC/AT compatible) CPU: 80486/25MHz or higher Memory: 8MB of system memory or higher 16-bit ISA internal slot Monitor Color or gray scale VGA or Super VGA compatible External Devices Mouse, hard disk and audio speakers or headphones DOS Ver 5.0 or higher;...

  • Page 80: Midi Implementation Chart

    Date: 18. JAN. 1995 MIDI Implementation Chart Version: 1.00 Transmitted Recognized Remarks Function... Basic Default 1-16 Channel Changed 1-16 Mode Default Mode 3 Messages Altered Note 0-127 Number :True voice 0-127 Velocity Note ON 9nH, v=1-127 Note OFF After Key’s Touch Ch’s Pitch Bender...
  • Page 81 Expression Sustain 100, 101 RPN LSB, MSB All Sound Off Reset All Controls Prog Change :True # 0-127 Program number 1-128 System Exclusive :Song Pos. common :Song Sel. :Tune System :Clock Real Time :Commands :Local ON/OFF Messages :All Notes Off (123-127) :Active Sense :Reset...

  • Page 82: Channel Message

    Appendix CHANNEL MESSAGE (Reception) NOTE ON/OFF Note Number C-2–G8 Velocity 1–127 CONTROL CHANGE (CONTROL NUMBER) (PARAMETER) Modulation 0–127 Volume 0–127 Panpot 0–127 Expression 0–127 Sustain 0–127 CHANNEL MODE MESSAGE All SOUND OFF Message allows complete shut off of all sounds; however retains NOTE ON and HOLD ON channel messages. RESET ALL CONTROLLERS Reset controller’s value to default (below): PITCH BEND...
  • Page 83 Appendix MEMO...

  • Page 84: Index

    Appendix I N D E X ABOUT button ........19 Decay Rate/Level ....... 49 IIR Filter (Infinite Impulse Response Filter) 31, 32, 33 About DSP Delay, Echo and Surround Effects 23 Default .... 6, 10, 14, 16, 45, 67, 71 Initialization ........
  • Page 85 Appendix Mic ........... 21 Paste button ........41 Thru ..........30, 31 Mic (Microphone) ....... 21 Patch ..........44 Tile ........... 50 Mic Channel ........29 PATCH (Instrument) LIST ......73 Toolbar ........40, 46 Mic Echo ....... 26, 28, 31 PC-SPK (Computer speaker) ....
  • Page 86 SOFTWARE LICENSING AGREEMENT The following is a legal agreement between you, the end user, and Yamaha Corporation (“Yamaha”). The enclosed Yamaha software program is licensed by Yamaha to the original purchaser for use only on the terms set forth herein. Please read this licensing agreement with care. Opening this package indicates that you accept all terms outlined herein.
