Appendix 1: Receivers Front and Back Panels

The layout of your DIRECTV

Standard-Definition Receiver

FRONT PANEL:
The buttons on the front panel perform the same functions as similarly named buttons on the remote control. You can use the front panel
buttons at any time, but they are especially useful if you misplace your remote control or the batteries die.
1
DIRECTV USER GUIDE - HD & SD STANDARD RECEIVERS
94
Receiver's front and back panels may vary slightly depending on model and manufacturer.
®
2 3 4 5
Your equipment may not look exactly like the model illustrated.
6 7 8 9
