LPD Queues

The LPD Queues page allows you to specify LPD (line printer daemon) print queues on the Jetdirect
print server. For more information on LPD printing and print queues, see
LPD printing must be enabled on the print server before you can set LPD queues. If LPD is disabled,
go to the Misc. Settings
If LPD printing is enabled, ten different named print queues are available. Four of these queues are
configured automatically and their parameters cannot be changed. The remaining six queues can be
defined by the user.
The six user-defined queues can be set up with character strings—such as job control commands—
that are automatically added before or after the print job. You can define up to eight named strings,
and you can set up each queue so that any of these named strings precedes the print data ("prepend
string name") or follows the print data ("append string name").
LPD Queue Parameters for setting up LPD queues are described below. See
Parameters.
Table 4-13 LPD Queue Parameters
Item
Queue Name
Prepend String Name
Append String Name
ENWW
tab to enable it.
Description
Name of the user-defined queue. This name can be up to 32 characters long, and can
consist of any displayable ASCII characters. You can define up to six user-defined queues.
CAUTION Avoid the differentiation of queue names through the use of lower- and
upper-case characters only. Otherwise, management of LPD queues by other tools
(such as Telnet) may yield unpredictable results.
Enter the name of one or more strings to be added before (or prepended to) the print data.
You specify string names and values in the table at the bottom of the page.
To prepend a long string, multiple string names may be concatenated, that is, entered and
separated by a "+" character. For example, to prepend a long string that has been divided
into two separate strings, enter:
<stringname1>+<stringname2>
where stringname1 and stringname2 are specified as two separate string names with
different values.
Enter the name of one or more strings to be added after (or appended to) the print data. You
specify string names and values in the table at the bottom of the page.
To append a long string, multiple string names may be concatenated, that is, entered and
separated by a "+" character. For example, to append a long string that has been divided
into two separate strings, enter:
<stringname1>+<stringname2>
where stringname1 and stringname2 are specified as two separate string names with
different values.
LPD Printing.
Table 4-13 LPD Queue
Networking Tab 81
