Site Requirements
Table 2-11 Power Requirements and Heat Dissipation—Fast Ethernet Switching Modules
Model Number/
Module Type
WS-X6324-100FX-SM
24-port 100BASE-FX Ethernet
module, SMF
WS-X6524-100FX-MM
24-port 100BASE-FX Ethernet
module
Table 2-12
Table 2-12 Power Requirements and Heat Dissipation—10/100 Ethernet Switching Modules
Model Number/
Module Type
WS-X6148-RJ-21
48-port 10/100 Ethernet module
WS-X6148-RJ21V
48-port 10/100 Ethernet module
with WS-F6K-VPWR PoE
daughter card
WS-X6148-21AF
48-port 10/100 Ethernet module
with WS-F6K-FE48-AF PoE
daughter card
WS-X6148-RJ-45
48-port 10/100 Ethernet module
WS-X6148-RJ45V
48-port 10/100 Ethernet module
with WS-F6K-VPWR PoE
daughter card
WS-X6148-45AF
48-port 10/100 Ethernet module
with WS-F6K-FE48-AF PoE
daughter card
WS-X6148A-RJ-45
48-port 10/100 Ethernet module
WS-X6148A-45AF
48-port 10/100 Ethernet module
WS-X6148X2-RJ-45
96-port 10/100 Ethernet module
Cisco 7600 Series Router Installation Guide
2-14
Module Module
Current (A) Power
(Watts)
1.52 63.84
1.90 79.8
lists the power and the heat numbers for the 10/100 Ethernet switching modules.
Module Module
Current (A) Power
(Watts)
2.39 100.38
2.39 100.38
2.57 107.94
2.39 100.38
2.39 100.38
2.57 107.94
1.00 42.0
2.57 107.94
2.65 111.30
AC DC
AC-Input Heat Diss. DC-Input
Power (BTU/HR) Power
(Watts) (Watts)
79.8 272.52 85.81
99.75 340.65 107.3
AC DC
AC-Input Heat Diss. DC-Input
Power (BTU/HR) Power
(Watts) (Watts)
125.48 428.5 134.92
125.48 428.50 134.02
134.93 460.77 145.08
125.48 428.50 134.92
125.48 428.50 134.92
134.93 460.77 145.08
52.5 179.29 56.45
134.93 460.77 145.08
139.13 475.11 149.60
Chapter 2 Preparing for Installation
Heat Diss.
(BTU/HR)
293.03
366.3
Heat Diss.
(BTU/HR)
460.75
460.75
495.45
460.75
460.75
495.45
192.78
495.45
510.87
