Cisco 7609 Router

Cisco 7609 Router
This section describes the Cisco 7609 Router (part number CISCO7609). Information on the Cisco 7609
Note
Router (product number OSR-7609) is in the Cisco 7609 Router Installation Guide, located at this URL:
http://www.cisco.com/univercd/cc/td/doc/product/core/cis7600/hardware/
osrouter/index.htm
The Cisco 7609 router chassis has nine vertical slots that are numbered from right to left. (See
Figure
The Cisco 7609 Router supports the following:
•
•
•
•
•
•
•
For a detailed description of supervisor engine operation in a redundant configuration, refer to the
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide.
Cisco 7600 Series Router Installation Guide
1-12
1-11.)
A Supervisor Engine 2 in slot 1 and an optional redundant Supervisor Engine 2 in slot 2. Each
supervisor engine provides switching, local and remote management, and multiple GBIC uplink
ports. If a redundant supervisor engine is not required, slot 2 is available for an OSM or other
supported Catalyst 6500 series modules.
The GBIC uplink ports are fully functional on the redundant supervisor engine in standby
Note
mode.
Both supervisor engines in a single chassis must be completely identical.
Note
A Supervisor Engine 720 in slot 5 and an optional redundant Supervisor Engine 720 in slot 6. Each
supervisor engine provides switching, local and remote management. The Supervisor Enigne 720
has two GBIC uplink ports and one 10/100/1000 Tx port. Only two of the three ports can be active
at any one time.
Note The GBIC uplink ports are fully functional on the redundant supervisor engine in standby
mode.
A Supervisor Engine 32 in slot 5 and an optional redundant Supervisor Engine 32 in slot 6. Each
supervisor engine provides switching, local and remote management.
A Route Switch Processor 720 in slot 5 and an optional redundant Route Switch Processor 720 in
slot 6. Each supervisor engine provides switching, local and remote management.
Both supervisor engines in a single chassis must be completely identical.
Note
Up to eight additional hot-swappable Catalyst 6500 series modules and SPA interface processors
(SIPs)
Hot-swappable, redundant fan assemblies
Redundant AC-input and DC-input ) power supplies
Chapter 1 Product Overview
OL-4503-26
