Installing the Stabilizer Kit (Cisco 7609 Router, Cisco 7609-S, and Cisco 7613 Router Only)
Open the stabilizer kit package and use the kit contents list in
included.
Table 3-1
Quantity
16
2
Have a second person available to perform this procedure.
Note
To install the stabilizer brackets, perform these steps:
Step 1
Have one person tilt and hold the chassis to one side.
Step 2
With the chassis tilted, attach the stabilizer bracket to the side of the chassis with the eight M4 screws
as shown in
Cisco 7600 Series Router Installation Guide
3-14
Stabilizer Kit Contents
Part Description
M4 Phillips countersunk-head screws
Stabilizer brackets
Figure
3-15.
Chapter 3
Installing the Cisco 7600 Series Router
Table 3-1
to verify that all parts are
Received
OL-4503-26
