Setup
HDMI ON/OFF
Use to enable/disable the HDMI connector. The default setting is
HDMI ON.
To set the HDMI ON/OFF option:
1. When the HDMI ON/OFF parameter is displayed on the front
panel display, press the remote control ENTER button.
2. Use the remote control
ON and HDMI OFF. When you have chosen the desired option
(it is displayed on the front panel), press the remote control
ENTER button.
Note:
To use the HDMI function, set the HDMI parameters in the SETUP
menu. See "HDMI Menu Options" on page 3-29.
HDMI RESET
Use to reset the RT-20 if HDMI functionality is not working properly.
To set HDMI RESET:
1. Use the remote control
RESET parameter.
2. Press the remote control ENTER button to select the parameter.
3. "SURE" appears on the front panel display. Press the remote
control ENTER button to activate HDMI RESET; or press the
remote control SETUP button to exit the menu without activating
the parameter.
3-34
/ buttons to toggle between HDMI
/ buttons to highlight the HDMI
Note:
If images are not properly displayed on the display device after config-
uring the HDMI setting on the SETUP menu, reset the RT-20. This will
return the HDMI setting to the state before the setting was made.
REMOT_CODE
Assigns a remote control command mode to the RT-20. When
DVD_1 is selected, the RT-20 can be operated with an RT-20
remote control to which the DVD_1 command mode is also
assigned. DVD-2 is the default command code.
To assign the DVD_2 command mode to the remote control:
Press and hold the remote control STOP and number 2 buttons for
about 5 seconds.
When DVD_1 is selected, the RT-20 can be operated with an RT-20
remote control to which the DVD_1 command mode is also
assigned.
To assign the DVD_1 command mode to the remote control:
Press and hold the remote control STOP and number 1 buttons for
about 5 seconds.
Note:
The DVD_1 command mode is intended for use when two RT-20s are
installed in the same system. Otherwise, avoid assigning the DVD_1
command mode to the RT-20 and the RT-20 remote control. When two
RT-20s are installed in the same system, assign the DVD_2 command
mode to one RT-20 and the DVD_1 command mode to the other
RT-20.
