RT-20 Universal Disc Player
the selection, playback mode reactivates from the beginning of
the selected chapter or track.
• Pressing and holding the
loaded disc in forward direction at 1/2 normal playback speed.
When the button is released, playback mode reactivates at the
current playback time.
• When the end of the disc is reached, pressing the
performs no function.
FRONT PANEL DISPLAY INDICATORS
The numbers in the front panel display illustration shown here
correspond with the numbered items below.
1. Indicates that a scene recorded from multiple angles is playing.
2. Indicates that the RT-20 component video output connectors
are passing progressive-scan (non-interlaced) video signals.
1
22
DOF F
23
24
25
/ button scans through the
/ button
2 3 4 5 6 7 8 9
GRP RNDM TRK A-B
TITLE PROG CHP ALL 1
28
26 27 29
3. Indicates that the number below in the character display is a
DVD-A group number.
4. Indicates a Remote Control Signal is being received.
5. Indicates that random playback is activated.
6. Indicates that the number below in the display is a DVD-A, CD,
Video CD or MP3 track number.
7. Indicates that a DTS source is present.
8. Indicates that A-B repeat playback is activated.
9. Indicates that repeat playback is activated.
10. Indicates that a Dolby Digital source is present.
11. Indicates that a SACD is loaded.
12. Indicates that a DVD-V is loaded.
13. Indicates that a 192kHz or 96kHz source is present. The sample
rate appears in red.
14. Indicates that pause is activated.
10 11 12 13 14
192 kHz
96 kHz
AUDIO TOTAL SING
30 31 32
Basic Operation
15 16 17 18 19 20 21
COND MP3 N P M
VCD
ELAP DOWN MIX
36
37
STEREO MULTI
33 34 35
2-5
