RT-20 Universal Disc Player
HDMI Audio Setup Table
HDMI Setting
(Audio)
Audio Formats
Dolby Digital
Dolby Digital*
Dolby Digital Karaoke
Dolby Digital *
Linear PCM Left/Right
DTS
1
DTS*
MPEG 1
MPEG*
DVD-A 2
*
3 Left/Right
CD/MP3/SACD*
DTS CD DTS
VCD Left/Right
*1: The RT-20 automatically switches to PCM output when the connected device
does not support Dolby Digital, DTS or MPEG bit streams.
*2: Output will be 48kHz/16-bit or 44.1kHz/16-bit. Multi-channel PCM sources are
downmixed to channel 2. (A source whose downmixing is prohibited is only output
to Front L/R).
*3: In this case, audio is not output from SACDs. Only the CD Audio part is output.
HDMI Setting
(Audio)
Auto PCM
1 2 CH DOWNMIX
1 Left/Right
Left/Right
2 CH DOWNMIX
Left/Right
2
*
Left/Right
DTS
Left/Right
FRONT PANEL DISPLAY MENU
Use to configure HDMI settings and the remote control command
mode. Unlike the Setup menu, the Front Panel Display Menu opens
on the RT-20 front panel display, which provides one-line viewing
of parameters and settings.
Parameter Default
HDMI ON/OFF HDMI OFF
HDMI RESET N/A
REMOT CODE DVD_2
To open the Front Panel Display menu:
1. Press the STOP button to activate stop mode. In some cases,
the STOP button must be pressed twice in succession to activate
stop mode.
2. If the Setup menu is closed, proceed to step 3. If the Setup
menu is open, press the remote control SETUP button to close
the Setup menu.
3. When stop mode is activated, press and hold the SETUP button
for more than 2 seconds. The front panel Display Off button
LED will begin blinking, indicating that the Front Panel Display
Menu is lit on the front panel display.
When the Front Panel Display Menu is open, the HDMI ON/
OFF parameter appears on the front panel display.
Note:
To close the Front Panel Display menu, press the remote control SETUP
button.
Setup
Possible Settings
HDMI OFF, HDMI ON
DVD_2, DVD_1
3-33
