RT-20 Universal Disc Player
Widescreen 16:9 Display Device Table
DVD Format
16:9*
16:9*
4:3
4:3
4:3
*
or other widescreen format
RT-20 TV Display
Aspect Device Ratio
Parameter Setting
16:9 (Wide) Normal (4:3)
16:9 (Wide) Full (16:9)
16:9 (Wide) Normal (4:3)
16:9 (Wide) Full (16:9)
16:9 (Squeeze) Full (16:9)
Appearance of Picture
The picture appears "squashed" with black bars at either side.
Set the display device to Full 16:9.
Images appear in widescreen (16:9) format.
Images appear between black bars at either side of the image.
Images appear stretched across the screen. Set the display
device to Normal (4:3).
Images appear between black bars at either side of the screen.
This setting is recommended for display device with a fixed
aspect ratio and a progressive-scan component video input
connector.
