RT-20 Universal Disc Player
Speaker Distances Table
Parameter Default
Unit Feet
L/R 10ft
C 10ft
LS/RS 10ft
LFE (sub) 10ft
To set speaker distances:
1. Select the Audio Setup1 Distance parameter.
2. Using the remote control
Unit (of measurement) setting.
3. Using the remote control
speaker icons.
4. When the desired parameter is highlighted, press the
buttons to cycle through available settings.
5. When settings are complete, press the RETURN button to
return to the Setup menu.
Selecting Initial causes all settings to return to their default.
Note:
To determine the appropriate setting for each speaker, measure the dis-
tance between the listening position and the front baffle of the speaker.
Then set the associated speaker distance parameter to the closest
available value.
Possible Settings
Feet, Meters
1 foot to 40 feet (3m to 12m)
Within 15 feet (4.5m) of the L/R settings
Within 15 feet (4.5m) of the L/R settings
Within 15 feet (4.5m) of the L/R settings
and buttons, select the desired
or buttons, cycle through the
The L/R distance parameter setting affects all other speaker distance
parameter settings. The C, LS, RS and LFE (sub) parameters must be
set within 15 feet (4.5m) of the L/R parameter.
Note:
• Select the closest available setting when the subwoofer distance falls
outside the LFE (sub) parameter range. This should not affect sur-
round cohesion.
• It is also possible to set the Distance parameter for SACD by setting
Super Audio CD Play to PCM. See "Super Audio CD Play" on page 3-
17.
LEVEL
Controls front, center, surround, and subwoofer channel output
levels when the RT-20 is using the 5.1-channel analog audio output
connectors.
Note:
This parameter setting has no effect when the RT-20 is using the
2-channel analog audio output connectors or digital audio output con-
and
nector.
Selecting Fix configures all channels to pass audio at its relative
recorded volume level. Selecting Variable opens the Gain Level Set-
ting screen, which can be used to adjust output levels within a
–6.0dB to +6.0dB range (in .5dB increments). See the "Gain Set-
tings Level Table (for all speakers)" on page 3-14.
Setup
3-13
