Appendix H: Non-patchable (Type 2) Parameters.

These are the non patchable parameters that are the same for all algorithms.
Param#
Dec Hex Description
0 00 Tempo (Rate)
when mode is Pgm
1 01 AR threshold
(AR ENV TLVL)
2 02 Switch 1 threshold
(SW 1 TLVL)
3 03 Switch 2 threshold
(SW2 TLVL)
4 04 Latch Low Threshold
5 05 Latch High Threshold
6 06 AR Env Source
7 07 Switch 1 source
(Sw1 TSRC)
8 08 Switch 2 source
(Sw2 TSRC)
9 09 Latch source
10 0A Tap duration
11 0B Tempo beat value
12 0C Tap average (tap window)
13 0D Adjust knob lower limit
14 0E Adjust knob upper limit
15 0F Adjust Knob Mid Point
16 10 Custom Control 1
Lower Limit
17 11 Custom Control 1
Upper Limit
18 12 Custom Control 1
Mid Point
19 13 Custom Control 2
Lower Limit
20 14 Custom Control 2
Upper Limit
21 15 Custom Control 2
Mid Point
Max
Value Notes
360 Add 40 to parameter value to derive BPM, ie Parameter Value of
80=120 BPM
127
127
127
127
127
255
255
255
255
14 0=1/8 beat
1=1/7 beat
2=1/6 beat
3=1/5 beat
4 =1/4 beat
5=1/3 beat
6=1/2 beat
7=1 beat
8=2 beats
9=3 beats
10=4 beats
11=5 beats
12=6 beats
13=7 beats
14=8 beats
6 0=Eighth Note
1=Dotted Eighth
2=Quarter Note
3=Dotted Quarter
4=Half Note
5=Dotted Half
6=Whole Note
6 2 Taps to 8 Taps
127
127
127
127
127
127
127
127
127
