0x20 Meter response
This dump is only transmitted by the PCM 90 when the automatic verbose mode is selected. It is
transmitted whenever the meter values change. For data reduction purposes, there is no LED change.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x20
6 000i iiii
7 000i iiii
8 0xF7
0x21 Patch Display Response
PCM 90 to host only. This dump returns the current display for a specified patch at a specified input value.
It is useful for an editing program that doesn't know the display specifics for a parameter.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x21
6 0n
7 0n
8-22 0iii iiii
23 0xF7
0x22 Matrix Mapping Response
PCM 90 to host only. This dump is a response to a request for information. The request holds
DestinationList ID and Destination List Index. This message returns the parameter that is mapped to that
location in the edit matrix. These are required when translating to and from the stored effect format.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x22
6 0iii iiii
7 0iii iiii
8 0iii iiii
9 0iii iiii
10 0xF7
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
Meter message
Left Meter bitmask
Right Meter bitmask
End of SysEx
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
Patch display data
Patch (0-9)
Pivot point (0-127)
15-char display string
End of SysEx
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
matrix mapping data
Dest List ID
Dest List Index
See Parameter Dump.
Parameter offset
End of SysEx
PCM 90 MIDI Implementation Details
Notes
Same as the LED message description.
Notes
This should be an assigned point.
See Overview for information on ASCII characters.
Notes
These two fields are used in the Single Effect packet.
Dependent on parameter type and algorithm.
23
