PCM 90 MIDI Implementation Details
0x0C Button Dump
This is bidirectional. Those buttons which are transmitted in SysEx Automation are: Compare, Tap and
Bypass.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0xC
6 0iii iiii
7 0xF7
Button SysExes may be sent in quick succession (faster than 40ms) to mimic holds. For example, sending
Proram Banks every 20ms for a period of 1 second will cause the Help message for the key to be displayed,
just as if the key on the front panel had been held down. Multiple key combinations can also be sent by
sending button messages in quick succession. For example, sending an Up message immediately
followed by a Down message causes the user interface to go to the 0.0 position in the current matrix, just
as if those two buttons were pressed simultaneously.
0x11 Card Name Message
This message which can be sent only via MIDI to the PCM 90 allows a card to be renamed. The name
of any currently-loaded card may be learned using the Configuration Response.
Byte # Byte Value
1 F0
2
3
4
5
6-15
16 0xF7
14
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
Button message
Button #
End of SysEx
Description
SysEx ID
06
08
0iii iiii
0x11
0iii iiii
End of SysEx
Notes
0=Up
1=Down
2=Program Banks
3=Load
4=Register Banks
5=Store
6=Edit
7=Compare
8=Control
9=Bypass
10=Tempo
11=Tap
12=Reserved
13=Footswitch 1
14=Reserved
15=Footswitch 2
Notes
Lexicon ID
PCM 90 ID
Device ID
Card Name
New name of card (10 Bytes). See ASCII Character Data.
