PCM 90 MIDI Implementation Details
0x7F Data Request
Host to PCM 90 only. The host may request that a message be sent by the PCM 90.
Byte # Byte Value
1 F0
2 06
3 08
4 0iii iiii
5 0x7F
6 0iii iiii
7-11 .........
12 0xF7
Request Request Byte
System
Config 0x00
Effect Bulk 0x01
Effect Single 0x02
Table 0x03
Table
element 0x04
Chain Bulk 0x05
Chain 0x06
Chain
element 0x07
Display 0x08
Param 0x0B
Soft Row 0x12
Patch 0x13
Param spec 0x16
Param display 0x17
System setup 0x18
Effect Info 0x1A
Bank Labels 0x1B
Custom
Control Name 0x1C
KeyWords 0x1D
Patch Display 0x21
Matrix Mapping 0x22
Soft Row
Display 0x24
26
Description
SysEx ID
Lexicon ID
PCM 90 ID
Device ID
Data request
Type of data
requested
parameters for
request
End of SysEx
Parameter bytes
none
Bank
Bank, Offset
TableID
TableID, Offset
Chain Group
ChainID
ChainID, Offset
none
Type, Offset
Offset (0-9)
PatchID (0-9)
Type, Offset
Type, Offset
ID of setup
Bank, Offset
Bank
none
Patch#, Pivot Point
Destination List ID,
DestListIndex
AlgID
Notes
This matches the message IDs described above, but not all
messages may be requested. See the table below.
These depend on the type of message requested. Any
unused parameters should be set to 0. See the table below
Notes
See Appendix C: MIDI Bank Assignments.
0x7F returns dump of currently-running effect, including any
unsaved edits.
0=Internal; 1=External (card)
Return dump of current display.
Dependent on type and algorithm.
Return matrix positions mapped to specified soft row offset.
Offset must be 0- 49.
0x7F for currently running algorithm.
