RP-7 Valve
The RP-7 Valve's pitch bending effect allows you to smoothly shift between two preset pitch intervals using the CC Pedal.
Amount
Whammy
Har (Harmony)
Values
Amount (EP5)
Key (EP6)
Scale (EP7)
The RP-7 also offers intelligent harmony pitching that lets you select the key, scale and amount of shifting in the signal. The parameters are
as follows:
Amount
Key
Scale
Note: For complete reference guide to these scales, please refer to the Harmony interval charts located in the Appendix section on
page 21.
User Guide
Selects the function of the Whammy™ Module. There are 16 functions available in regular Whammy
Modules. They are as follows:
1= Up 1 Octave
2=Up 2 Octaves
3=Down 2nd Reversed
4=Down 2nd
5=Down 4th
6=Down 1 Octave
7=Down 2 Octaves
8=Down 6 Octaves
The Whammy Parameter reflects the current setting of the Whammy™ effect. This Parameter should be
linked to the RP-7 Valve's CC pedal. As Position is modified, the pitch of the original note will change in
intervals according to the setting of the WHAMMY TYPE. Ranges from 0 to 100.
Displayed Values
O c t d . . . O c t u
. . . G # o
a
1 . . . 1 4
Amount lets select how much the pitch is shifted. This Ranges from: -Octave down-Octave Up
This parameter lets you select which key the harmony shifting takes place in. This ranges from: A to G#.
This parameter lets you select the scale that is being used in the Harmony effect. There are fourteen
different scales and they are numbered as follows: 1. Major 2. Minor 3. Harmonic Minor 4. Melodic
Minor 5. Dorian 6. Mixolydian 7. Lydian 8. Lydian Augmented 9. Major Pentatonic 10. Minor
Pentatonic 11. Blues 12. Whole Tone 13. Half-Whole Dimished 14. Whole-Half Dimished
Section - 4 Effects and Parameters
9=Down 1 Oct - Up 1 Oct
10=Down 4th - Down 3rd
11=Up 5th - Up 6th
12=Up 4th - Up 5th
13=Up m3rd - Up Maj 3rd
14=Up 2nd - Up 3rd
15=Shallow Detune
16=Deep Detune
17
