8. Secure your DLT-VS80 Internal Drive with the appropriate mounting screws (see Note
below), either in the sides or bottom of the drive sled, as appropriate for the server or
workstation chassis. Figure 2-11 shows the drive without the power and SCSI cables
attached for clarity.
Figure 2-11: Secure DLT-VS80 Internal Drive in Installation Bay (Side Mounting Screws
Note: Some servers and workstations require mounting rails for internal devices. Contact
your server or workstation manufacturer for information.
Note: Use screws provided. Using an alternative length screw could cause damage to the
unit. If an alternative screw must be used, it cannot extend more than 0.10" into the unit.
9. Replace the cover on the server or workstation.
10. Attach the power cables to the server or workstation and all attached accessories.
11. Turn on the host server or workstation and allow its operating system to start.
Refer to the next section to learn about your DLT-VS80 Internal Drive's self-test and
initialization features.
2-16
Shown)
