4. Attach the other end of the SCSI cable to the connector on your SCSI host adapter or to
the connector on the previous SCSI device on the SCSI bus.
To Next SCSI Device
To SCSI Host Adapter

Figure 2-3: Attach SCSI Cable to Server or Workstation or to Previous SCSI Device

2-6
SCSI Host Adapter
FC Tw DLTVS80 e SCSI
Cable
