Wire colors and connection points for connection wires
Never connect the power supply to the speaker wires (No.7 and No.8),
otherwise it will cause damage to the main unit.
Caution
1
ACC (Red)
Connect where the power comes on when the ignition is in the ACC position.
2
B+ (Yellow)
Connect where power is constantly available, regardless of the ignition key's position.
Ground (Black)
3
Connect where good body grounding is available.
Antenna power supply (Blue)
4
Connect to the automatic-antenna control terminal of the vehicle.
5
Illumination power supply (Orange/White)
Connect to where power comes on when the vehicle light switch is turned on.
Control power supply (Blue/White)
6
Connect the control terminal for the external amplifier, etc.
Front speaker output wires
7
Connect to the front speakers.
Rear speaker output wires
8
Connect to the rear speakers.
9
Genuine factory steering remote control terminal
Connect to the vehicle steering remote control.
Compatible vehicle models for installation : Vehicles with voltage detection-type steering remote control.
White:
Left +
White/black:
Gray:
Right +
Gray/Black:
Green: Left +
Green/black:
Purple: Right +
Purple/Black:
Ask your dealer for details.
- 6 -
2
Left -
Right -
Left -
Right -
