Components
Components
Main unit
1
x 1
Bezel
5
x 1
Bushing
9
x 1
Tip
When installing the main unit, some vehicle models may require the use of items that need to be
obtained separately such as a power supply adaptor wire, radio antenna adaptor wire or mounting
bracket.
Check that all of the following components are present
Check that all of the following components are present
Interconnecting wires
2
(Power and speaker connector)
(16P) x 1
Hex-head bolt
6
(Red:M5x8) x 4
10 Remote control
x 1
- 2 -
Mounting sleeve
3
x 1
Flat head screw
7
(Red:M5x8) x 4
Case
11
(For detachable panel) x 1
Side bracket
4
x 2
Stud bolt
8
x 1
Battery
12
x 2
