Eclipse CD5000 - - Radio Installation Manual page 10

2) CD4000 + HDR105 + CH3083 + Power Amplifer
TO GROUND
2P
HDR105
(sold separately)
13P
TO GROUND
INTERCONNECTING WIRES
(supplied with CH3083)
TO BATTERY+12V
(Permanent Supply)
ANTENNA PLUG
ANTENNA EXTENSION WIRE
13P
TO BATTERY+12V
NO CONNECTION
(Permanent Supply)
(Do not remove cap)
13P
CH3083
2P
(sold separately)
TO ACC (Power Supply)
TO POWER ANTENNA RELAY (Supply)
TO HEAD LIGHT SWITCH (Illumination (+) )
TO TURN-ON WIRE OF EXTERNAL EQUIPMENT (Supply)
- 10 -
NO CONNECTION
(Do not remove cap)
16P
13P
White
Yellow
White/Black
Gray
Gray/Black
Green
Red
Green/Black
Blue
Purple
Orange/White
Purple/Black
Blue/White
Brown
Brown/Black
Black
TO GROUND
2
NO CONNECTION (Do not remove cap)
TO SIGNAL INPUT OF AUXLIARY
POWER AMPLIFIER
1
MAIN UNIT
INSULATE EACH WIRE WITH NONE
CONDUCTING TAPE SUCH AS
PLASTIC TAPE OR ANOTHER
INSULATING METHOD
INSULATE EACH WIRE WITH NONE
CONDUCTING TAPE SUCH AS
PLASTIC TAPE OR ANOTHER
INSULATING METHOD
TO STEERING REMOTE CONTROL
INTERCONNECTING WIRES
(Power and speaker connector)
