Displaying Connection Status

Use the Port Status page to display the current connection status, including
link state, auto-negotiation, speed/duplex mode, and flow control.
Field Attributes
• Type – Shows port type as:
- 10/100TX
- 1000LX:
• Enabled – Shows if the port is enabled or disabled.
• Status – Indicates if the link is Up or Down.
• Mode – Shows the port speed and duplex mode.
• Flow Control – Indicates the type of flow control in use.
Console – Click Status and Counters=>Port Status.
Port
---- --------
1. 10/100TX
2. 10/100TX
3. 10/100TX
4. 10/100TX
5. 10/100TX
6. 10/100TX
7. 10/100TX
8. 10/100TX
9. 1000FX
actions->
Tab=NextItem
10BASE-T / 100BASE-TX
1000BASE-LX
Tiger Switch 10/100 6709GL2 : Port Status
===========================
Type Enabled
-------
No
Yes
No
No
No
Yes
No
Yes
No
<Quit>
Select the action menu.
BackSpace=Previous Item
S
TATUS AND
Status
------ ---------
Down 100 Full
Up 100 Full
Down 100 Full
Down 100 Full
Down 100 Full
Up 100 Full
Down 100 Full
Up 100 Full
Down 1000 Full
Quit=Previous menu
C M
OUNTERS
Mode FlowCtrl
--------
On
Off
On
On
On
Off
On
Off
On
Enter=Select Item
ENU
4-7
