Introduction; Key Features - SMC Networks 6709GL2 INT Management Manual

This switch provides a broad range of features for switching. It includes a
management agent that allows you to configure the features listed in this
manual. The default configuration can be used for most of the features
provided by this switch. However, there are many options that you should
configure to maximize the switch's performance for your particular
network environment.

Key Features

Feature
Authentication
Configuration
Backup / Restore
Port Configuration Speed, duplex mode and flow control
Port Mirroring
Static Address
Trunks
Spanning Tree
Protocol
Virtual LANs
Traffic
Prioritization
Multicast Filtering Supports IGMP snooping and query
I
Description
Console, Telnet, Web – User name / password
SNMP – Community strings
Backup to TFTP server
One or more ports mirrored to single analysis port
Up to 8K MAC addresses in the forwarding table
Static trunks or dynamic Link Aggregation Control Protocol
Supported
Up to 128
Supports two priority queues; queuing based on First-In
First-Out (FIFO), high queue before low queue, or Weighted
Round Robin (WRR)
C
HAPTER
NTRODUCTION
1
1-1
