Displaying System Information

Use the System Information page to display basic information on the
switch, including hardware/firmware version numbers for the main board
and management software.
Field Attributes
• System Description – Switch model number.
• MAC Address – The physical layer address for this switch.
• Firmware Version – Version number of runtime code.
• Hardware Version – Hardware version of the main board.
• Default config value version – Default configuration version.
Console – Click Status and Counters=>System Information.
System Description
MAC Address
Firmware version
Hardware version
Default config value version
ESC = Previous menu
Tiger Switch 10/100 6709GL2:Management Address Information
===========================
Display the switch system.
S
TATUS AND
: Tiger Switch 10/100
: 0050BF97A4E0
: V003.6
: A002.000
: V026.000
C M
OUNTERS ENU
4-9
