VLAN Configuration Menu

Use the VLAN Configuration menu to specify the VLAN type used on
this switch, configure VLAN groups, or set the default VLAN identifier
and ingress filtering for each port.
Tab=Next Item
Menu
VLAN Configure
Create a VLAN Group
Edit/Delete a
VLAN Group
4-20
Tiger Switch 10/100 6709GL2 : VLAN Configuration
===========================
VLAN Configure
Create a VLAN Group
Edit/Delete a VLAN Group
Previous Menu
Configure the VLAN PVID and Ingress Rule.
BackSpace=Previous Item
Description
Sets port VID and ingress filters
Configures VLAN groups, including name,
identifier, and if limited to a specific protocol
Modifies VLAN groups, including name,
identifier, and if limited to a specific
protocol; or deletes a specified group
Quit=Previous Menu Enter=Select Item
Page
4-21
4-23
4-21
4-23
