To Use Set Ip - Ricoh Aficio BP20 User Manual

2.34 S U Y
ETTING P OUR

To Use Set IP

1
From the Start menu, select Aficio BP20 Series in
Programs, and click Set IP.
2
Click to find printer on the local network, or click
and type the printer's MAC address.
N : To confirm the MAC address, see the NETWORK PRINTER
OTE
CARD TEST PAGE. The NETWORK PRINTER CARD TEST PAGE will
be printed after the Configuration Page. To Print the Configuration
Page, refer to "Printing Configuration Pages" on page 5.8.
3
Type IP address, Subnet Mask and Default Gateway, and
then click [Config].
4
If it is successfully completed, the printer prints NETWORK
PRINTER CARD TEST PAGE.
