Power Cord Requirements for AC-Powered Switches
and AC Power Supplies
IEEE 802.3 Media Access Standards
IEEE 802.3ab 1000BASE-T
IEEE 802.3at PoE
IEEE 802.3ae 10GBASE-X
IEEE 802.3az Energy Efficient Ethernet
Power Cord Requirements for AC-Powered Switches and AC Power
Supplies
An AC power cord is not included with the AC power supply.
Power cords used with AC-powered switches or AC power supplies must meet the
following requirements:
•
The power cord must be agency-certified for the country of use.
•
The power cord must have an appropriate AC connector for connection to the switch
or power supply.
•
The power cord must have an appropriately rated and approved wall plug applicable
to the country of installation.
•
For cords up to 6 feet (2 m) long, the wire size must be 18 AWG (.75 mm
over 6 feet, the minimum wire size is 16 AWG (1.0 mm
For details about obtaining AC power cords for use in your country, refer to
www.extremenetworks.com/product/powercords/.

Console Connector Pinouts

Table 22
Table 22: Pinouts for the DB-9 Console Connector
Function
DCD (data carrier detect)
RXD (receive data)
TXD (transmit data)
DTR (data terminal ready)
GND (ground)
DSR (data set ready)
RTS (request to send)
CTS (clear to send)
Figure 65
108 ExtremeSwitching 5320 Series Hardware Installation Guide
describes the pinouts for a DB-9 console plug connector.
shows the pinouts for a 9-pin to 25-pin (RS-232) null-modem cable.
Technical Specifications
2
).
Pin Number
1
2
3
4
5
6
7
8
2
) minimum;
http://
Direction
In
In
Out
Out
-
In
Out
In
