Log in for the First Time on Switch Engine
•
Stop bit: 1
•
Parity: None
Log in for the First Time on Switch Engine
Before You Begin
Onboard your switch with ExtremeCloud™. Log in or create your XIQ administrator
account in order to select your switch operating system with XIQ at
extremecloudiq.com
Switch Engine is the default operating system for the 5320 Series. If you want to run
Fabric Engine, see
Change the Switch OS via the Startup Menu
Note
Fabric Engine does not support models 5320-24T-4X-XT and 5320-24T-24S-4XE-
XT.
Before logging in, verify that the switch LEDs are on (solid green or blinking green)
and that it is connected to a management console as described in
Management Console
About This Task
To perform the initial login and complete initial configuration tasks, follow these steps.
Procedure
1. Using a terminal emulator such as PuTTY or TeraTerm, connect to the switch using
the serial port connection. You can also connect to the switch via telnet or SSH.
Be sure that your serial connection is set properly:
•
Baud rate: Baud rate: 115200
•
Data bits: 8
•
Stop bit: 1
2. At the management console, press [Enter] one or more times until you see the login
prompt.
3. At the login prompt, log in using the default user name admin.
For example:
login: admin
When you have successfully logged on to the system, the command line prompt
displays the system name (for example, 5320-24T-8XE-SwitchEngine#) in its
prompt. You are logged in with administrator privileges, which gives you access to all
switch functions.
82 ExtremeSwitching 5320 Series Hardware Installation Guide
Change the Switch OS via the Bootloader Menu
on page 81.
Note
For the initial password, simply press [Enter].
Activate and Verify the Switch
on page 85.
https://
on page 84 or
Connect to a
