Section 4: Syslog Overview

This Syslog feature can send real time system information on a web page or to a specified
PC. The Twin WAN Gateway will permit up to three machines from which to send the
system log to.
Message Status
When Keep sent Message is checked, the Twin WAN Gateway keeps the last 100
messages in RAM. These messages will clear when the gateway reboots or is powered
off.
Syslog Configuration Settings
Syslog Delivery
Sending Out - This enables the Twin WAN Gateway to send system log
messages to other PCs.
Keep Sent Messages - By default, sent syslog messages are deleted. When Keep
Sent Messages is enabled, the Twin WAN Gateway will keep sent syslog
messages.
Syslog Server -
IP Address:
Enable:
Port:
Log Prioriy Level: The syslog messages are divided into 8 levels from Emergency to
Copyright © 2005 WINS International, LLC dba XiNCOM | All rights reserved.
Up to three (3) syslog servers can be used.
You can enable or disable each server temporarily.
If your syslog server does not use the default port (514), you can
assign a different port.
Debug level. The lower the level, the less messages will be
generated. Emergency is the lowest priority level and Debug is the
highest one.
