Dispensing Fuel
(See page 60)
Be sure the fuel tank has fuel in it prior to operating the fuel pump.
Make sure the fuel is not contaminated with debris.
1.
Attach the grounding clip to the item or vehicle being fueled.
2.
Outside the RV at the fueling station, pull the master/emergency
disconnect switch to the "ON" position.
3.
Inside the RV, press the fuel pump momentary switch one time.
Pushing this switch turns on the pump, and a timer which will
automatically turn off the fuel pump after 15 minutes has elapsed
(pressing this switch two times turns off the timer and the pump).
4.
Outside the RV, insert the fuel nozzle into the receiving tank and
squeeze the nozzle handle to dispense the fuel. Fueling should
begin in 15 to 20 seconds.
EXHAUST GAS FUMES (page 55)
Avoid inhaling exhaust gases as they contain carbon monoxide, which
is a potentially toxic gas that is colorless and odorless.
If you are in a recreation vehicle with either a nearby tow vehicle
engine running or the generator (if equipped) running, there is a
potential for exhaust fumes to filter back into the recreation vehicle.
PROPANE GAS SYSTEM (page 55)
Propane cylinders should not be placed or stored inside RV. Propane
cylinders are equipped with safety devices that relieve excessive
pressure by discharging propane into the atmosphere. Propane gas
is highly flammable, can lead to fire or explosion, and result in death
or serious injury.
5.8.1.2.1
PROPANE GAS CONTAINER (page 55)
DOT propane cylinders must be transported and stored in an upright
position so the pressure relief device will function properly. Laying
a DOT propane cylinder on its side may potentially create a very
dangerous situation.
The pigtail hose must be installed to avoid tension or pulling stress at
either end of the hose. Keep the pigtail hose away from sharp edges
of the cylinder collar, rigid corners, walls, doors or other compartment
structures including the cover.
Before entering a propane or fuel service station make sure all pilot
lights are extinguished. Shut off gas to all appliances by closing the
propane gas main shut off valve. Always shut OFF any engine before
refueling. Do not smoke and do not operate other ignition sources
while refueling.
If you suspect your propane container has been overfilled, contact
your dealer or a qualified propane technician for assistance
immediately. Do not attempt to service a propane container overfill
yourself.
FUEL & PROPANE SYSTEM
5.
When fueling is complete, release the nozzle handle to stop the
flow of fuel. Replace the nozzle back into the fueling station
storage box.
6.
Turn off the master/emergency disconnect switch by pushing the
knob in.
7.
Disconnect the grounding clip.
8.
Inside the RV, press the fuel pump switch next to the fuel gauge
two times to cancel the timer and turn off the pump.
If the timer shuts off the pump before fueling is completed, turn on
the fuel pump switch inside the RV. This will start another 15-minute
cycle.
Running the fuel dispensing pump for more than 5 minutes with the
fuel nozzle closed will reduce the fuel pump motor life.
FUEL & PROPANE SYSTEM WARNING
FUEL FILLER CAP (page 55)
Do not replace the fuel fill cap with one of a different type. Use of a
substitute cap may create excessive fuel system pressure, resulting in
fuel station damage and improper operation in a collision.
Fuel can spray out on you if you open the fuel filler cap too quickly.
This can happen if your tank(s) is nearly full and is more likely to
happen in hot weather.
FUEL PUMP MOMENTARY SWITCH (page 55)
IF THE FUEL STATION EQUIPMENT DOES NOT FUNCTION AS
INTENDED, DISCONTINUE USE AND HAVE THE FUEL STATION
SERVICED BEFORE RESUMING USE.
PROPANE REGULATORS (page 56)
Propane regulators must always be installed with the regulator
vent facing downward. Regulators that are not located in baggage
compartments have been equipped with a protective cover. Make sure
the regulator vent faces downward and (if applicable) the cover is in
place to minimize vent blockage that could result in excessive gas
pressure causing fire or explosion.
5.8.1.2.7
COOKING WITH PROPANE GAS (page 57)
Do not turn gas range burner controls to ON and allow gas to escape
before lighting.
Do not use portable fuel burning equipment (i.e., wood and charcoal
grills or stoves) inside the recreation vehicle.
FUEL TANK FUEL SELECTION (page 57)
Working with fuel can be dangerous. Serious injury or death could
result from improper handling of the generator, fuel station and fuel.
7
