WLR 8900/8905
Programming Guide
Please Read
Note:
The Wasp WLR 8900/8905 Scanner is ready to scan the
most popular bar codes out of the box. This manual
should only be used to make changes in the
configuration of the scanner for specific applications.
This scanner does not require software or drivers to
operate. The scanner enters data as keyboard data. Please
review this manual before scanning any of the programming
bar codes in this manual.
Tech Tip
If you are unsure of the scanner configuration or have
scanned the incorrect codes, please scan the default
bar code on page 6. This will reset the scanner to its
factory settings.
Check Version
Advertisement
Table of Contents
Related Manuals for Wasp WLR8900
Summary of Contents for Wasp WLR8900
-
Page 1: Programming Guide
Programming Guide Please Read Note: The Wasp WLR 8900/8905 Scanner is ready to scan the most popular bar codes out of the box. This manual should only be used to make changes in the configuration of the scanner for specific applications. - Page 2 Wasp Technologies. The information contained in this document is subject to change without notice. Wasp is a trademark of Wasp Technologies. All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Table of Contents Chapter 1. Introduction ...1 Chapter 2. Bar Code Symbologies...2 Chapter 3. Installation...3 Chapter 4. Quick Start ...4 Chapter 5. WLR 8900/8905 Setup & Configuration ...5-28 Appendix A Bar Code Test Symbols ...28-30 Appendix B ASCII Table ...31-34 Appendix C Codes for PC ...35 Appendix D... -
Page 4: Chapter 1. Introduction
Wasp WLR 8900 series scanners extremely rugged since they have no moving parts. Wasp WLR 8900 series scanners are support PS/2 or USB keyboard interfaces and easily wedges between the computer and keyboard. -
Page 5: Bar Code Symbologies
(greater than 0.020 in./0.50 mm). Medium and low densities are the most common since these are the easiest to read (scan) with nearly all scanning devices. Wasp WLR 8900/8905 Scanners can read bar codes with X-dimensions as low as 5 mils (0.005 in/0.13mm). -
Page 6: Chapter 3. Installation
8900 Scanner directly into your PC keyboard port. Plug your keyboard cable into the other end (female Din 6) of the the scanner. Turn your computer on. WLR 8905 USB Scanner Plug the USB of the WLR 8905 Scanner directly into your PC’s USB port. Trigger Din-6M Din-6F Trigger... -
Page 7: Chapter 4. Quick Start
Chapter 4 Quick Start Your Wasp WLR 8900/8905 Scanners are ready for use. The default settings of the scanners have been pre-programmed for the most common bar code configurations. Use the “WLR 8900/8905 Setup & Configuration” sections only to customize the scanners settings. Please review the “Enable Bar Code Symbologies”... -
Page 8: Chapter 5. Wlr 8900/8905 Setup & Configuration
In order to configure Wasp WLR 8900/8905 Scanners, you must familiarize yourself with the setup procedures on the following pages. The default settings of the Wasp WLR 8900/8905 Scanners are identified on each page and clearly marked using an asterisk (*). The default settings have been preprogrammed for the most common bar code configurations. -
Page 9: Factory Default & Keyboard Connection
Autosense Flash Mode Enable Keyboard Connection The Keyboard Connection is used to program the Wasp WLR 8900/8905 Scanners for the type of computer it is attached. PC - AT (PS/2) * PC - XT... -
Page 10: Beep And Delay
Beep and Delay The 'Beep and Delay' configuration supports the general control options for the Wasp WLR 8900/8905 Scanners. These options include the volume, intercharacter delay, and interblock delay. Interblock delay is the minimum time interval between two adjacent scans. If the processing speed of your host device is slower than your scanning speed, a longer interblock delay may ensure the data integrity. -
Page 11: Beep And Delay
Chapter 5 Beep and Delay Interblock Delay 0ms * 10ms 50ms 100ms 200ms 500ms Intercharacter Delay 140µs * 500µs 16ms *Default... -
Page 12: Upper/Lower Case
• Caps Lock Auto (For PC XT/AT only): In Auto Trace mode, the scanner will keep track of the Caps Lock status automatically. For some PCs, the scanning performance may be compromised because of the auto tracing. If the scanning performance... -
Page 13: Keyboard Language
Chapter 5 Keyboard Language The ‘Keyboard Language’ setting controls the key codes for your keyboard’s language. U.S. * German French Spanish Italian *Default... -
Page 14: Preamble/Postamble Configuration
The ‘Preamble/Postamble’ configuration is used to add a prefix or suffix set of characters to the bar code value. Up to 8 characters may be added for each option separately. Preamble and postamble characters can function concurrently, but need to be configured separately. To add preamble or postamble characters, follow the steps below: 1) Scan the ‘Clear Pre/Postamble’... -
Page 15: Terminator/Code Id
Chapter 5 Terminator/Code ID Terminator The ‘Terminator’ option is used to specify the end-of-text message and is primarily used to denote the end of the bar code value. CR * None CR + LF Code ID The ‘Code ID’ option sends a specific value when a particular bar code symbology is scanned. -
Page 16: Enable/Disable Bar Code Symbologies
Enable/Disable Bar Code Symbologies Enable Enable All MSI Plessey Interleaved 2 of 5 * Code 128 * Codabar * Code 39 * Chapter 5 Disable Disable All MSI Plessey * Interleaved 2 of 5 Code 128 Codabar Code 39 *Default... -
Page 17: Enable/Disable Bar Code Symbologies
Chapter 5 Enable/Disable Bar Code Symbologies Enable UPC A * UPC E * EAN 8 * EAN 13 * Code 93 Disable UPC A UPC E EAN 8 EAN 13 Code 93 * *Default... -
Page 18: Bar Code Symbology Settings
Code 39 is variable length and is the most frequently used symbology in industrial bar code systems today. It is extensively used within the Department of Defense (DOD). The principal feature is to encode messages using the full alphanumeric character set. Standard Code 39 contains only 43 characters (0-9, A-Z, $, /, %, +, -, ., SPACE) and can be extended to a 128 character symbology (full ASCII) by combining one of the special characters (S, /, %, +) with a letter (A-Z) to form the characters that are not present in the standard Code 39 symbology. -
Page 19: Interleaved 2 Of 5 And Code 93
Chapter 5 Interleaved 2 of 5 and Code 93 Settings Interleaved 2 of 5 is a variable length, even numbered, numeric bar code. It is typically used in industrial and master carton labeling and also in the automobile industry. The symbology uses bars to represent the first digit of a pair and the interleaved (white) spaces to represent the second digit of a character pair. -
Page 20: Code 128 And Ucc/Ean 128
Code 128 is the most flexible of all the common linear symbologies. It supports alpha and numeric characters easily, has the highest number of characters per inch, and is variable length. See page 5 for information on setting the minimum and maximum lengths. Enable Code 128 * Disable Code 128 UCC/EAN 128... -
Page 21: Msi/Plessey
Chapter 5 MSI Plessey Settings MSI Plessey is a variable length numeric symbology and is primarily used in marking retail shelves. Each character consists of four bars with intervening spaces for each encoded digit, one or two symbol check digits, and a reverse start code. See page 5 for information on setting the minimum and maximum lengths. -
Page 22: Codabar
Codabar is a variable length symbology capable of encoding six special alphanumeric characters, capital letters A through D, T, N, *, E, and all numeric digits. Codabar is one of the oldest bar code symbologies and is still used in some library applications. It should not be considered for new applications except under unusual circumstances. -
Page 23: Upc-A
Chapter 5 UPC-A Settings UPC-A (Universal Product Code-A) is fixed length and is the most common UPC bar code for retail product labeling. It is seen in most grocery stores across the United States. The symbology encodes a 12-digit number. The first six digits are assigned from the Uniform Code Council (UCC). -
Page 24: Upc-A Supplemental / Upc-A To Ean-13
UPC-A Supplement Settings / UPC-A to EAN-13 This option enables the two and five digit supplements for the UPC and EAN/JAN bar code symbologies. 5 Digit Supplement Enable 2 Digit Supplement Enable Transmit if Present This option expands the UPC-A bar code to EAN-13. UPC-A to EAN-13 Enable Chapter 5... -
Page 25: Upc-E
Chapter 5 UPC-E Settings UPC-E (Universal Product Code-E) is fixed length and is a compressed six digit code used for marking small packages, including magazines and paperback books. UPC-E symbols are UPC-A symbols that have been zero suppressed (i.e. consecutive zeros are not included in the symbol). -
Page 26: Upc-E Supplemental
This option enables the two and five digit supplements for the UPC and EAN/JAN bar code symbologies. 5 Digit Supplement Enable 2 Digit Supplement Enable Transmit if Present Chapter 5 UPC-E Supplement Settings 5 Digit Supplement Disable * 2 Digit Supplement Disable * Must Be Present * *Default... -
Page 27: Ean-8
Chapter 5 EAN-8 Settings The EAN/JAN-8 is fixed length and is similar to the UPC-E code, but includes two more digits for the country code. The nominal height for the EAN/JAN-8 bar code is one inch. The reduced size is 80% of the nominal size. EAN-8 Enable * Send Leading Digit * Send Check Digit *... -
Page 28: Ean-8 Supplemental
This option enables the two and five digit supplements for the UPC and EAN/JAN bar code symbologies. 5 Digit Supplement Enable 2 Digit Supplement Enable Transmit if Present Chapter 5 EAN-8 Supplement Settings 5 Digit Supplement Disable * 2 Digit Supplement Disable * Must Be Present * *Default... -
Page 29: Ean-13
Chapter 5 EAN-13 Settings The EAN/JAN-13 (European Article Number/Japanese Article Number) is fixed length and is similar to the UPC-A symbology, but encodes a 13th digit. The nominal height for the EAN/JAN-8 bar code is one inch. The reduced size is 80% of the nominal size. EAN-13 Enable * Send Leading Digit * Send Check Digit *... -
Page 30: Ean-13 Supplemental
This option enables the two and five digit supplements for the UPC and EAN/JAN bar code symbologies. 5 Digit Supplement Enable 2 Digit Supplement Enable Transmit if Present Chapter 5 EAN-13 Supplement Settings 5 Digit Supplement Disable * 2 Digit Supplement Disable * Must Be Present * *Default... -
Page 31: Appendix A Bar Code Test Symbols
Appendix A Bar Code Test Symbols Note: Make sure that the appropriate bar code symbology is configured properly and enabled before trying to scan. Use the 'Bar Code Symbologies' configuration beginning on page 18 to enable specific symbologies. Code 39* Code 93 Interleaved 2 of 5 * Codabar *... - Page 32 Appendix A Bar Code Test Symbols UPC-A* UPC-A w/5 digit supplement UPC-A w/2 digit supplement UPC-E* UPC-E w/5 digit supplement UPC-E w/2 digit supplement *Default...
- Page 33 Appendix A Bar Code Test Symbols EAN/JAN-13* EAN/JAN-13 w/5 digit supplement EAN/JAN-13 w/2 digit supplement EAN/JAN-8* EAN/JAN-8 w/5 digit supplement EAN/JAN-8 w/2 digit supplement *Default...
-
Page 34: Appendix Bascii Table
Use this ASCII Table to add preamble and postamble characters to your bar code value. Please refer to the appropriate configuration section for the number of characters that can be configured. ASCII Character Appendix B ASCII Table... - Page 35 Appendix B ASCII Table " & ASCII Character < >...
- Page 36 ASCII Character Appendix B ASCii Table...
-
Page 37: Ascii Table
Appendix B ASCII Table ASCII Character... -
Page 38: Appendix C Codes For Pc
Back Tab Back Space Appendix C Function Code for PC Cursor Right Cursor Up Cursor Left Cursor Down Page Down Home Page Up Enter... -
Page 39: Appendix D Technical Specifications
Appendix D Technical Specifications MODEL PERFORMANCE Sensor Depth of Field Best Resolution Scan Rate Decoding Rate Scanning Width Sunlight MECHANICAL Dimensions Weight Cable ELECTRICAL Operating Voltage POWER CONSUMPTION ENVIRONMENTAL Operating Temperature Storage Temperature Relative Humidity Mechancial Shock Conformance SYMBOLOGIES 1.2" 1.6"... -
Page 40: Product Support
Product Support If you experience any problems with Wasp WLR 8900/8905 Scanners that you are unable to resolve, call for technical assistance at (214) 547-4100, Monday through Friday, 8:00 AM - 5:00 PM Central Standard Time. Our web site is www.waspbarcode.com... -
Page 41: Frequently Asked Questions
Frequently Asked Questions Q: How do I configure the scanner for a notebook (or laptop) computer? A: Scan the “Notebook” bar code on page 6. Q: How do I change the terminator to a Tab? A: Scan the “Tab” bar code on page 12.
