Summary of Contents for Nexus NEO
- Page 1 NEO / NEO WIFI AMBIENT TEMPERATURE & POWER REGULATOR CONTROL Stone Connect Wi-Fi INSTALLATION, OPERATING AND USER MANUAL MAY ONLY BE PERFORMED BY QUALIFIED PERSONS PNEOr to installing and using the temperature controller, please carefully read this manual and keep it for future reference...
-
Page 2: Table Of Contents
IF NEO / NEO WIFI IS NOT CONNECTED TO THE HEATING ELEMENT ..........13 5.5.2 IF NEO / NEO WIFI INCL. HEAT. ELEMENT IS NOT CONNECTED TO THE TOWEL RAIL ....15 Cleaning ..........................16 Uninstalling NEO / NEO WIFI ..................17 Notes for disposal of NEO / NEO WIFI valid for the European Union ..... - Page 3 7.9.2 Timing ..................................26 7.9.3 Factory reset ................................. 27 7.10 Lock ............................ 27 7.11 WIFI connection ........................ 28 Maintenance ............................29 Diagnostics.............................. 29 10 Supplied accessories, consumables and spare parts ..............29 11 Power cable size reduction ........................30...
-
Page 4: General Warnings
The guarantee of NEO / NEO WIFI is not valid in case of improper use or wrong installation. 1.3 Product compliance... -
Page 5: Safety Warnings
• Do not power NEO / NEO WIFI on before it has been completely installed in a properly filled towel rail with the electric heating element recommended by the manufacturer •... -
Page 6: Product Presentation
Any other use is strictly forbidden. The type of regulation is PI temperature regulation. NEO / NEO WIFI can be connected to a fully electric towel radiator or a hybrid electric-hot water heater (dual fuel, central heating radiator). - Page 7 Capacitive touchscreen interface displaying current system status (in black or white) Grub screw seat Position of the grub screw in order to fix NEO / NEO WIFI to the Electric heating element connection Power supply cable 230 V power supply cable with plug or without plug...
-
Page 8: Technical Specification Tables
NEO / NEO WIFI and the electric heating element power must be carefully selected in proportion to towel rail size and thermal output. To select NEO / NEO WIFI and the heating element electrical power, please refer to the towel rail manufacturer instructions, when a certification related to the complete system (according to EN 60335-2-30) issued by an European recognized institute (like SEMKO, VDE, IMQ…) is available. -
Page 9: Installation - Qualified Technicians Only
5.1 Before you start • Avoid collisions during the handling. Do not deform NEO / NEO WIFI. • Avoid the contact of cables and of parts of the NEO / NEO WIFI with sharping corners and do not cause squashing. -
Page 10: Towel Rail Warnings
• Before installation, never switch the NEO / NEO WIFI on to verify functioning effectiveness. • Don’t use the NEO / NEO WIFI regulating box to lean the electrical towel rail on the floor as you can damage the plastic housing and water can penetrate inside with a risk of electrical shock. -
Page 11: Neo / Neo Wifi Position
5.4.1 TOWEL RAIL POSITION • Do not install NEO / NEO WIFI into a towel rail fitted in ZONE 0 or ZONE 1 (Zone definition IEC 60364-7-701 in Figure 3). • The towel rail must be installed in a completely vertical wall. -
Page 12: Supply Cord Position
5.4.3 NEO / NEO WIFI REGULATING BOX POSITION • NEO / NEO WIFI must only be fitted vertically in the bottom part of the towel rail. • Electrical towel rail must NOT be installed with the NEO / NEO WIFI regulating box located at the top. -
Page 13: Neo / Neo Wifi Installation
NEO / NEO WIFI is fully inserted. b. Keep NEO / NEO WIFI pressed against the heating element in the towel rail and insert the provided grub screw into its spot; make sure there is no room between... - Page 14 Using the provided Allen key tighten the grub screw until it comes into contact and it is fully inserted in its spot, so that the NEO / NEO WIFI is securely fixed to the electric heating element and the O-ring gasket is well in contact with both surfaces c.
-
Page 15: If Neo / Neo Wifi Incl. Heat. Element Is Not Connected To The Towel Rail
• Make sure that the towel rail can have the NEO / NEO WIFI on the bottom side (Figure • If the heating element or the controller is damaged, do not continue with the... -
Page 16: Cleaning
Do not clean NEO / NEO WIFI with aggressive products. Do not wet NEO / NEO WIFI in an attempt to clean it. Do not immerse in water. When cleaning NEO / NEO WIFI, it must be disconnected from the power supply. -
Page 17: Uninstalling Neo / Neo Wifi
• The electrical towel rail with regulator is intended only for heating rooms in the home. Any other use is forbidden • NEO / NEO WIFI is intended to be used and installed into a towel rail. Any other use is strictly forbidden and potentially dangerous. -
Page 18: Controller Functions
• Once connected to the heating element, NEO / NEO WIFI regulating box MUST NOT be disconnected from the heating element. • Do not cover NEO / NEO WIFI, even partially, even temporarily. ONTROLLER UNCTIONS 7.1 NEO / NEO WIFI buttons maps... -
Page 19: First Start
7.2 First start First start Set Hour, Minute and Day. -
Page 20: Standard Functions On-Off
7.3 Standard functions ON-OFF Display backlight Tap any button one time to turn on the display from the stand-by mode (display off). Display will light on. Backlight for the display: off after 5 second and on when a button is touched. Backlight on: Tap ON-OFF button to switch on the controller. -
Page 21: Mode Selection
7.4 Mode selection Display backlight Tap any button one time to turn on the display from the stand-by mode (display off). Display will light on. Tap ON-OFF button to switch on the controller Mode button To switch between the operating modes. Mode Temperature setting Comfort... -
Page 22: Boost Mode
7.6 Boost mode Display backlight Tap any button one time to turn on the display from the stand-by mode (display off). Display will light on. Tap ON-OFF button to switch on the controller Boost / Dryer Select Boost in order to work at maximum heating level. Tap >... -
Page 23: Weekly Program Edit
7.7 Weekly program edit Display backlight Tap any button one time to turn on the display from the stand-by mode (display off). Display will light on. Tap ON-OFF button to switch on the controller Mode button Tap mode button to reach the operating modes Weekly Program If you don't press any button for 3 minutes the timing process program will exit without saving. -
Page 24: Weekly Program View
7.8 Weekly program view Display backlight Tap any button one time to turn on the display from the stand-by mode (display off). Display will light on. Tap ON-OFF button to switch on the controller Mode button Tap mode button to reach the operating modes Weekly Program... -
Page 25: Secondary Functions
7.9 Secondary functions Mode button To switch between the secondary functions. Long press the mode (Open window / Timing / Factory reset) you want to edit as shown in next points 7.9.1 Open window... -
Page 26: Timing
7.9.2 Timing... -
Page 27: Factory Reset
7.9.3 Factory reset 7.10 Lock Lock function Disable all the buttons. Long press the ON/OFF button while in Comfort / Eco / Antifreeze mode to activate the lock function. -
Page 28: Wifi Connection
App, open it and register (if necessary) or enter as a guest. This App includes a guided installation menu and provides instructions for putting the NEO WIFI in pairing mode (search for Smart Device that can accept the connection via WIFI). -
Page 29: Maintenance
• Never try to modify or repair the NEO / NEO WIFI in any of its parts by yourself. Never try to remove any part of the NEO / NEO WIFI as water can penetrate inside the regulation box resulting in a risk of electrical shock. -
Page 30: Power Cable Size Reduction
Never try to modify or repair the NEO / NEO WIFI in any of its parts by yourself. Never try to remove any part of the NEO / NEO WIFI as water can penetrate inside the regulation box resulting in a risk of electrical shock. - Page 31 Brown (black): phase 230 V / 50 Hz Blue: neutral conductor Yellow-green: protective conductor (earth) The manufacturer assumes no responsibility for any damage to the equipment or personal injury caused by improper installation of the cable, reversed polarity, insulation damage or any other intervention, connection or wiring that is not in compliance with the applicable regulations.
