Vodavi Telenium IP Installation Manual

The following are the network and wiring requirements for successful Telenium
electrical requirements, please consult the Telenium
1. Inside wiring:
a) A minimum of Category 5 wiring. Although the Telenium
phones where a CAT5 connection is not possible, an RJ45 jack must be available for each digital IP phone used.
b) One Ethernet (RJ-45 type) jack at each station location. If only one jack per desktop exists, PCs and phones can
share the Ethernet jack and wiring by using the Vodavi 2-Port IP Phones.
Based on the above requirements, a 10/100Mbps network built to support PCs meets the minimum requirements for
installing Telenium IP systems, provided it uses at least CAT5 wiring. New wiring will be needed for locations not meeting
these requirements.
A Note on Fiber: Ethernet/Gigabit Ethernet Fiber Optic, if used, can carry the IP traffic of the Telenium
However, all of Telenium IP
to be used in order for Telenium
2. Existing Ethernet devices, if used:
a) Ethernet switches will provide better performance than hubs. A dedicated switch which is separate from the data
traffic can provide still better performance.This can be accomplished by patching the desktop LAN ports directly
into the SHUB8, the Ethernet switch component of Telenium
b) A direct connection to the Telenium
LAN cable. In cases where existing LAN infrastructure uses other LAN switches, the SHUB8 modules can
be distributed wherever needed to provide this direct connection.
3. Wide Area Networking:
If using IP Telephony to connect the Telenium
at each site:
Sites linked via point-to-point IP WAN:
a) An Ethernet or Fast Ethernet connection to the data network, via a LAN switch or hub (preferably a switch).
b) One available I P address to assign the Telenium
be configured to use the same router IP address [default gateway] and subnet mask as the local network.
c) Any type of IP WAN circuit capable of providing sufficient bandwidth for the anticipated IP phone calls plus any
data traffic that may also be using the connection.
Telenium IP
's network interfaces are Ethernet (RJ45).Therefore, fiber-to-Ethernet converters will need
IP 's modules or phones to communicate over fiber links.
IP 's SHUB8 module is a requirement to power the IP phones via the
IP system to another phone system or gateway, this is what is needed
Site Requirements
IP Installation Manual.
IP does have SLT gateway modules for supporting SLT
IP .
IP system, which is valid on the local network.The Telenium
© 2003 Vodavi Communications Systems, Inc.
IP installation. For environmental and
IP system.
IP will
