SAFETY NOTICE:
If this appliance is not properly installed, a house
fire may result. For your safety, follow the
installation directions. Contact local building or
fire officials about restrictions and installation
inspection requirements in your area.
French language manual can be found at lopistoves.com
Les manuel en français sont disponibles sur lopistoves.com
Copyright 2023,
Travis Industries, Inc.
$10.00
100-01593
2/13/2024
Rockport
NexGen-Hybrid
Wood Stove
Owner's Manual
• Freestanding Stove
• Mobile-Home (US) & Transportable
Building (CA) Approved
• Alcove Approved
• Hearth-Stove Approved
Save these instructions
for future reference
Report #0028WS100S & 0028WS139E
Conforms to UL STD 1482-2022; Certified to ULC S627-2023
Listed by
Omni-Test Laboratories, Inc
