Summary of Contents for BEMIS bioBidet SLIM THREE
-
Page 2: Product Information
PRODUCT INFORMATION Important Safeguards Overview & Parts Wireless Remote Registration and Installation Resources GETTING STARTED Functions & Features INSTALLATION Installation Guide Questions? We’re here to help. MAINTENANCE 847.458.2334 Cleaning Tips support@biobidet.com Draining the Water Tank www.biobidet.com Troubleshooting Guide Specifications Technical support and alternate fittings are available. - Page 3 PLEASE OBSERVE THE FOLLOWING PRECAUTIONS AND INSTRUCTIONS BEFORE INSTALLATION AND USE. • This product must be connected to a grounded 120V GFCI (ground fault circuit interrupt) outlet. Do not connect the power cord if it is damaged or broken. Do not plug the product into a loose electrical outlet. •...
- Page 4 Slim Three Slim Three Parts List Power Plug T-Valve Top Mount Mounting Washers Rubber Nuts Bolts *Rubber Washer Inside Remote Receiver Dryer Bolt Guides Catch Plate Bidet Hose Night Light Seat Sensor Stainless Steel Nozzle Heated Seat Side Control Panel Remote Remote Control...
-
Page 5: Functions And Features
Functions & Features Stop Button The Slim Three is a bidet toilet seat designed for superior hygiene, comfort, and sustainability. Each use will leave you feeling clean Rear Wash and confident, while reducing your overall eco footprint. Front Wash Sit Down On The Seat Turbo Wash This product includes a built-in seat sensor that must be activated with skin contact in order to operate bidet functions. - Page 6 Child Wash Adjustable Nozzle Position Press to activate a child-friendly wash with low water pressure, Adjust the nozzle position forward or backward to achieve maximum cleanliness and comfort by pressing the “Front” or “Rear” buttons. low water temperature, and an extra extended nozzle position. This wash consists of a one-minute bidet wash followed by 30 seconds of oscillation and 30 seconds of the massage function.
- Page 7 3. Install Catch Plate BEFORE INSTALLATION Insert the top mount rubber nuts into the toilet mounting holes. Place the catch plate and bolt guides over the mounting holes. Insert the mounting bolts through Do not plug the power cord in until installation is complete. the washers, guides, catch plate, and into the top mount rubber nuts.
-
Page 8: Installing The Remote
5. Connect the Water Hoses Install the t-valve onto the toilet tank. Ensure the rubber washer is properly seated inside the t-valve. Connect your existing toilet hose to the water shut-off valve and t-valve. Toilet Tank Connect the provided bidet hose to the bidet seat and t-valve. Open the water shut-off valve. -
Page 9: Cleaning The Strainer
Cleaning the Strainer Draining the Water Tank *Close shut-off valve *Close shut-off valve Before draining, unplug This product will not operate properly if the strainer is clogged. the power cord and wait Please clean the strainer regularly. 30 minutes until the unit has cooled down. - Page 10 Specifications Slim 3 Problem Solution Rated Voltage AC 120V, 60Hz • Check if the power Max Power Consumption plug is connected 870W Completely out of order • Check if the power supply or outlet has failed Power Cord Length 1.2 m Recommended Inlet Water Pressure 9.95 ~ 106.7 psi •...
- Page 11 1 YEAR FULL WARRANTY This warranty gives you specific legal rights. You may have other rights which vary from state to state. To obtain warranty repair service under this warranty, you must contact Bio Bidet Innovation LLC or an authorized distributor. Bio Bidet Innovation LLC warrants its product to be free from manufacturing defects under normal use and service for a period of one (1) year from This written warranty is the only warranty made by Bio Bidet Innovation LLC.
- Page 12 Customer Support T: 847.458.2334 TOLL-FREE: 877.339.5214 7900 S IL Route 31 Crystal Lake, IL 60014 support@biobidet.com www.biobidet.com...
