Quick Links
Tools
Phillips screw driver
Flat head screw driver
Contact
847.458.2334
support@biobidet.com
Lid Replacement
Remove Screws
•
Turn the unit upside down and take out the screws
that are holding down the control panel. Be sure to
use a phillips screw driver.
Discovery DLS
Seat Replacement
This is a guide for replacing the seat for the Discovery DLS. Follow along to the instructions
depending on which part you have that needs replacing instructions. Bio Bidet By Bemis is not
responsible for any damages that result from attempting this repair/replacement at home. If
you do not feel comfortable attempting this repair/replacement, please contact us to obtain an RMA
and return the bidet to our service center. *Be aware that replacing the seat involves wiring*
Before You Begin
•
Unplug the bidet
•
Turn off the water valve and drain the bidet
•
Disconnect the bidet from the water supply and toilet and place on
a flat, dry, and well-lit surface
Take Out Control Panel
•
After the screws have been taken out, use a
flat head screw driver to unlock the top housing
from the base by inserting the tip of a flat head
screw driver into the 2 slots on the bottom
and/or top.
•
You will have to use some force with the screw
driver to pop open the housing.
1
Advertisement
Related Manuals for BEMIS bioBidet Discovery DLS
Summary of Contents for BEMIS bioBidet Discovery DLS
- Page 1 Tools This is a guide for replacing the seat for the Discovery DLS. Follow along to the instructions depending on which part you have that needs replacing instructions. Bio Bidet By Bemis is not Phillips screw driver responsible for any damages that result from attempting this repair/replacement at home. If...
- Page 2 Discovery DLS Seat Replacement Remove Dampers • To replace the seat/lid, you will need to remove the seat and lid dampers first. • Use a phillips screwdriver to take out the first damper. Set the screws aside. • Remove the second damper using the same screwdriver. Set the screws aside. Unclip Wires •...
- Page 3 Discovery DLS Seat Replacement Replace Seat • Place the new replacement seat upside down down. • Line up the lid to the housing and lay it upside down shown in the second picture. It should be loosely connected. • Carefully thread the wires of the new seat through the side hole of the housing. Reattach Dampers •...
- Page 4 Discovery DLS Seat Replacement Reclip Wires To Control Panel • Reconnect the clipped wires back into the control board. There are red dots on the left photo that tell you which wires need to be connected again. The following color coded wires should be connected back from left to right: Black, Black, Blue •...
