CAS BACNET EXPLORER FOR VALIDATING PROTONODE IN THE FIELD
Sierra Monitor has arranged a complementary 2 week fully functional copy of CAS BACnet Explorer
(through Chipkin Automation) that can be used to validate BACnet MS/TP and/or BACnet/IP
communications of ProtoNode in the field without having to have the BMS Integrator on site. A serial
or USB to RS-485 converter is needed to test BACnet MS/TP.
8.1 Downloading the CAS Explorer and Requesting an Activation Key
•
To request the complementary BACnet CAS key, go to
and fill in all the information. Enter Vendor Code "Harsco12". This will register the email
address that was submitted.
•
Go to the following web site, download and install the CAS BACnet Explorer to the local
PC:
http://www.chipkin.com/technical-resources/cas-bacnet-explorer/.
•
Open CAS BACnet Explorer; in the CAS Activation form, enter the email address that was
registered and click on "Request a key". The CAS key will then be emailed to the registered
address. Cut/paste key from email into the Product key field and click "Activate".
Figure 25: Downloading the CAS Explorer
Figure 26: Requesting CAS Activation Key
