Stamina inMOTION Compact Strider Pro Owner's Manual page 8

ASSEMBLY INSTRUCTIONS
STEP 3
Attach the LEFT PEDAL CAP(53) to the LEFT PEDAL ARM(51) with BUTTON HEAD BOLTS
(M8x1.25x20mm)(54). Repeat on the other side.
NOTE: The LEFT and RIGHT PEDAL CAPS(53, 41) have a raised lip on three sides. Attach the LEFT
and RIGHT PEDAL CAPS(53, 41) to the LEFT and RIGHT PEDAL ARMS(51, 40) so that the side
without the raised lip is on the outside.
STEP 4
Loosen the QUICK RELEASE(82) by opening the Lever on the QUICK RELEASE(82). Insert the LOW
UPRIGHT(12) into the MAIN FRAME(27) until the BUTTON PIN(22) lock into the hole on the MAIN
FRAME(27). Tighten the QUICK RELEASE(82) to lock the LOW UPRIGHT(12) in position securely.
NOTE: When assembling or attaching the Handlebar, be sure the LOW UPRIGHT(12) is fully inserted into
the MAIN FRAME(27), the BUTTON PIN(22) is engaged, and the quick release lever is firmly in
the down position.
Hole
Lever
8
