32 en | RAID setup
7

RAID setup

If you have added third party hard drives to empty units, you must configure the hard drives
using the RAID setup utility.
Notice!
i
The RAID setup process is not necessary for units with pre-installed hard drives. These units
are delivered with a default configuration.
To configure the hard drive using RAID BIOS:
1.
2.
3.
4.
5.
6.
7.
8.
Refer to
–
2021.03 | V2 | DOC
Install all hard drives.
Turn on the system and press Ctrl+R when MegaRAID Configuration Utility is displayed
on the screen. The display appears before Windows starts.
In the MegaRAID Configuration Utility program, select Create Virtual Drive.
Apply the following settings:
– RAID Level: RAID-5 (alternatively RAID-6 or RAID‑5 plus hot spare)
– Under Advanced settings:
Strip Size: 64KB
Write Policy: Write Back
Note: All other settings remain unchanged.
Select all hard drives that are part of the RAID group.
Start the virtual drive initialization.
Exit the MegaRAID Configuration Utility program.
Perform a complete system recovery (Initial Factory Setup).
Recovering the unit, page 46
