Specifications - Polycom SoundPoint IP 335 Specifications

Polycom SoundPoint IP 335
Lines (Directory Numbers)
• Up to 2 lines with up to 2 calls per line
Display
• 102 x 33 pixel backlit grayscale graphical LCD
• LED backlight with custom intensity control
Feature Keys
• 3 context-sensitive "soft" keys
• 2 line keys with bi-color (red/green) LED
• 2 feature keys ("Menu" and "Dial")
• 4-way navigation key cluster with center "Select"
key
• 2 volume control keys
• Dedicated hold key
• Dedicated headset key
• Dedicated hands-free speakerphone key
• Dedicated microphone mute key
Headset and Hearing Aid Compatibility
• Dedicated RJ-9 headset port – amplified
headsets are recommended
• Compliant with ADA Section 508
Recommendations: Subpart B 1194.23 (all)
• Hearing Aid Compatible (HAC) handset for
magnetic coupling to approved HAC hearing aids
• Compatible with commercially available TTY
adapter equipment
Audio Features
• Polycom HD Voice technology delivers life-like
voice quality for each audio path – the handset,
the hands-free speakerphone and the optional
headset
1
• Full-duplex hands-free speakerphone
• Type 1 compliant with IEEE 1329 full duplex
standards
• Codecs: G.722 (wideband), G.711 µ/A and
G.729A (Annex B)
• Individual volume settings with visual feedback
for each audio path
• Voice activity detection
• Comfort noise fill
• DTMF tone generation/DTMF event RTP
payload
• Low-delay audio packet transmission
• Adaptive jitter buffers
• Packet loss concealment
• Acoustic echo cancellations
• Background noise suppression
Call Handling Features
2
• Shared call / bridged line appearance
• Flexible line appearance (one or more line keys
can be assigned for each line extension)
• Distinctive incoming call treatment/call waiting
• Call timer
• Call transfer, hold, divert(forward), pickup
• Called, calling, connected party information
• Local three-way conferencing
• One-touch speed dial, redial
• Call waiting
• Remote missed call notification
• Intercom
• Automatic off-hook call placement
• Do not disturb function
Polycom Worldwide Headquarters
4750 Willow Road, Pleasanton, CA 94588
1.800.POLYCOM or +1.925.924.6000
www.polycom.com
© 2010 Polycom, Inc. All rights reserved. POLYCOM
registered and/or common law marks in the United States and various other countries. All other trademarks are property of their respective owners. No portion hereof may be reproduced or transmitted in any form
or by any means, for any purpose other than the recipient's personal use, without the express written permission of Polycom.
Other Features
• Interoperability with Microsoft
telephony and presence
- Compatibility with Microsoft Office Communicator
and Windows
®
• Enabled for Polycom Productivity Suite
• Local feature-rich GUI
• Time and date display
• User-configurable contact directory and call
history (missed, placed and received)
• Wave file support for call progress tones
• Unicode UTF-8 character support. Multilingual
user interface encompassing Danish, Dutch,
English (Canada/US/UK), French, German,
Italian, Norwegian, Polish, Russian, Slovenian,
Spanish, Swedish
Protocol Support
• IETF SIP (RFC 3261 and companion RFCs)
Network and Provisioning
• Two 10/100 Mbps Ethernet port
• Manual or dynamic host configuration protocol
(DHCP) network setup
• Time and date synchronization using SNTP
• FTP/TFTP/HTTP/HTTPS server-based central
provisioning for mass deployments
• Provisioning and call server redundancy
supported
• Web portal for individual unit configuration
• QoS Support – IEEE 802.1p/Q tagging (VLAN),
Layer 3
• TOS and DSCP
• Network Address Translation (NAT) support
for static configuration and "Keep-Alive" SIP
signaling
• RTCP support (RFC 1889)
• Event logging
• Syslog
• Local digit map
• Hardware diagnostics
• Status and statistics reporting
Security
• Transport Layer Security (TLS)
• Secure Real-time Transport Protocol (SRTP)
• Encrypted configuration files
• Shipped with X.509 certificate installed
• Digest authentication
• Password login
• Support for URL syntax with password for boot
server
• HTTPS secure provisioning
• Support for signed software executables
Power
• Built-in, auto-sensing IEEE 802.3af Power Over
Ethernet (Class2)
• External universal input AC adapter (optional
24V DC@500mA)
Approvals
• FCC Part 15 (CFR 47) Class B
• ICES-003 Class B
• EN55022 Class B
• CISPR22 Class B
• AS/NZS CISPR 22 Class B
• VCCI Class B
• EN55024
• ROHS compliant
, the Polycom "Triangles" logo and the names and marks associated with Polycom's products are trademarks and/or service marks of Polycom, Inc. and are
®

Specifications

LCS 2005 for
®
3
Messenger 5.1 Clients
;
4
• GOST-R
• A-Tick
• C-Tick
• CCC
• KCC
Safety
• CE Mark
• EN 60950-1
• IEC 60950-1
• UL60950-1
• CAN/CSA-C22.2 No.60950-1-03
• AS/NZS 60950-1
Operating Conditions
• Temperature: 0 to 40°C (+32 to 104°F)
• Relative Humidity: 5% to 95%, non-condensing
Storage Temperature
• -40 to +70°C (-40 to +160°F)
SoundPoint IP 335 Comes With:
• SoundPoint IP 335 console
• Handset with handset cord
• Base stand
• Network (LAN) cable
• Quick Start Guide
• Product registration card
Size
• 6.7 in x 5.7 in x 6.9 in x 1.4 in
• (17 cm x 14.5 cm x 17.5 cm x 3.5 cm)
Weight
• Phone weight: 1.37 lb (0.625 kg)
Part Numbers /UPC Codes
• 2200-12375-025/610807694670 for all markets
Unit Box Dimensions / Weight
• 10 in x 4.2 in x 11.6 in (W x H x D)
• (25 cm x 10.5 cm x 29.5 cm)
• 3 lb 4 oz (1.49 kg)
Master Carton Quantity
• Ten
Country of Origin
• Thailand
Warranty
• 1 Year
1. To enjoy all the benfits of Polycom HD Voice
when using the phone in the headset mode, you
must use a wideband headset.
2. Some of these features need to be supported by
an appropriate call/applications server.
3. Features supported on SoundPoint IP 335
require, SIP 3.2.2 or later.
4. Optional AC Adapter 5-Packs, Part Numbers/
UPC Codes
• 2200-17877-001/610807690269 for
NA, CALA, Taiwan
• 2200-17877-002/610807690276 for Japan
• 2200-17877-012/610807630283 for
Australia/New Zealand
• 2200-17877-015/610807690290 for
UK, Ireland, HK, Singapore, Malaysia
• 2200-17877-016/610807693437 for Korea
• 2200-17877-022/610807693444 for China
• 2200-17877-122/610807690306 for
India, Europe, Rest of the world
1289_0210
