Specifications - Polycom SoundPoint IP 560 Specifications

Polycom SoundPoint IP 560
Lines (Directory Numbers)
• Up to 4 lines with up to 2 concurrent calls per line
Display
• 320 x 160-pixel backlit grayscale graphical LCD
• LED backlight with custom intensity control
Feature Keys
• 4 context-sensitive "soft" keys
• 26 dedicated "hard" keys
- 4 line keys with bi-color (red/green) LED
- 8 feature keys
- 6 display/menu navigation keys
- 2 volume control keys
- Illuminated mute key
- Illuminated headset key
- Illuminated hands-free speakerphone key
- Dedicated hold key
Headset Compatibility
• Dedicated RJ-9 headset port
- Amplified headsets are recommended
Hearing Aid Compatibility
• Compliant with ADA Section 508 Recommendations:
Subpart B 1194.23 (all)
• Hearing Aid Compatible (HAC) handset for
magnetic coupling to approved HAC hearing aids
• Compatible with commercially-available TTY adapter
equipment
Audio Features
• Polycom HD Voice technology delivers life-like voice
quality for each audio path - the handset, the
hands-free speakerphone, and the optional headset
• Full-duplex hands-free speakerphone
- Type 1 compliant with IEEE 1329 full duplex
standards
• Frequency response - 100Hz - 7kHz for handset,
optional headset and hands-free speakerphone modes
• Codecs: G.722 (wideband), G.711 µ/A, and G.729A
(Annex B)
• Individual volume settings with visual feedback for
each audio path
• Voice activity detection
• Comfort noise fill
• DTMF tone generation / DTMF event RTP payload
• Low-delay audio packet transmission
• Adaptive jitter buffers
• Packet loss concealment
• Acoustic echo cancellation
• Background noise suppression
2
Call Handling Features
• Shared call / bridged line appearance
• Flexible line appearance (one or more line keys
can be assigned for each line extension)
• Busy Lamp Field (BLF)
• Distinctive incoming call treatment / call waiting
• Call timer
• Call transfer, hold, divert (forward), pickup
• Called, calling, connected party information
• Local three-way conferencing
• One-touch speed dial, redial
• Call waiting
• Remote missed call notification
• Intercom
• Automatic off-hook call placement
• Do not disturb function
Polycom Headquarters:
www.polycom.com
Polycom EMEA:
Polycom Asia Pacific:

Specifications

Other Features
• Local feature-rich GUI
• Time and date display
• User-configurable contact directory and call history
(missed, placed, and received)
• Customizable call progress tones
• Wave file support for call progress tones
• Unicode UTF-8 character support. Multilingual user
interface encompassing Chinese, Danish, Dutch,
English (Canada / US / UK), French, German, Italian,
Japanese, Korean, Norwegian, Portuguese, Russian,
Spanish, Swedish
Protocol Support
• IETF SIP (RFC 3261 and companion RFCs)
Network and Provisioning
• Two-port Gigabit Ethernet switch
- 10/100/1000Base-Tx across LAN and PC ports
- Conforms to IEEE802.3-2005 (Clause 40) for
Physical Media Attachment
- Conforms to IEEE802.3-2002 (Clause 28) for Link
Partner Auto-Negotiation
• Manual or dynamic host configuration protocol (DHCP)
network setup
• Time and date synchronization using SNTP
• FTP / TFTP / HTTP / HTTPS server-based central
provisioning for mass deployments
• Provisioning and call server redundancy supported
• Web portal for individual unit configuration
• QoS Support – IEEE 802.1p/Q tagging (VLAN), Layer 3
TOS, and DSCP
• Network Address Translation (NAT) – support for static
configuration and "Keep-Alive" SIP signalling
• RTCP support (RFC 1889)
• Event logging
• Syslog
• Local digit map
• Hardware diagnostics
• Status and statistics reporting
Security
• Transport Layer Security (TLS)
• Encrypted configuration files
• Digest authentication
• Password login
• Support for URL syntax with password for
boot server address
• HTTPS secure provisioning
• Support for signed software executables
Power
• Built-in, auto-sensing IEEE 802.3af Power over
Ethernet
• External Source 48V DC @ 380mA
Approvals
• FCC Part 15 (CFR 47) Class B
• ICES-003 Class B
• EN55022 Class B
• CISPR22 Class B
• AS/NZS CISPR 22 Class B
• VCCI Class B
• EN55024
• EN61000-3-2; EN61000-3-3
• ROHS compliant
• Anatel
©2007 Polycom, Inc. All rights reserved.
Polycom, the Polycom logo and SoundPoint are registered trademarks and Polycom HD Voice is a trademark of Polycom, Inc. in the U.S. and various countries.
All other trademarks are the property of their respective owners. Specifications subject to change without notice.
4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) +1.925.924.6000, (F) +1.925.924.6100
270 Bath Road, Slough, Berkshire SL1 4DX, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
8 Shenton Way, #11-01 Temasek Tower, Singapore 068811 (T) +65.6389.9200, (F) +65.6323.3022
Part No. 3726-47004-001 Rev. 11/07
Safety
• CE Mark
• EN 60950-1
• IEC 60950-1
• AS/NZS 60950-1
• UL/C-UL
Operating Conditions
• Temperature: +10 to 40°C (+50 to 104°F)
• Relative Humidity: 20% to 85%, non-condensing
Storage Temperature
• -40 to +70°C (-40 to +160°F)
SoundPoint IP 560 Comes With:
• SoundPoint IP 560 console
• Handset with handset cord
• Base stand
• Network (LAN) cable
• Quick Start Guide
• Product registration card
Size
• 10.5 in x 6 in x 7.5 in x 2.5 in
(26.5 cm x 15 cm x 19 cm x 6.5 cm) (W x H x D x T)
Weight
• Phone weight: 2.4 lb (1.1 kg)
Unit Box Dimensions / Weight
• 12.5 in x 13.25 in x 3.5 in
• 4.0 lbs (1.8 kg)
Master Carton Quantity
• Five
Country of Origin
• Thailand
Warranty
• 1 year
1 In some calling scenarios, such as IP to PSTN, Polycom HD Voice will
not be available and the call will progress in narrowband instead.
2
Some of these features need to be supported by an appropriate
call/applications server.
