Intel Light-Guided Diagnostics
A
B
C
D
E
F
G
H
®
Intel Server System R2000GZ/GL Service Guide
System ID LED
System Status LED
POST Code Diagnostic LEDs
12V Stand By LED
CPU-2 Fault LED
System Fan – 6 Fault LED
System Fan – 5 Fault LED
System Fan – 4 Fault LED
®
Figure 11. Intel Light-Guided Diagnostic LEDs - Server Board
Server System Features
I System Fan – 3 Fault LED
J DIMM Fault LEDs
K System Fan – 2 Fault LED
L System Fan – 1 Fault LED
M CPU-1 Fault LED
N CATERR LED
O System Power Good LED
