*POWER REQUIREMENTS*

Read and understand all instructions before plugging any TRUE power cord into an electrical outlet.
*Power warnings, grounding instructions, and power requirements are only applicable when this product is being used
with the optional power supply.*
NOTE: The Envision II 16" and ShowRunner II consoles require the optional power supply.
DEDICATED LINE
This product does not require a dedicated line.
GROUNDING INSTRUCTIONS
This product must be grounded. If the product malfunctions or breakdowns, grounding provides a path of least resistance
for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment
grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed
and grounded in accordance with all local codes and ordinances.
DANGER:
!
• Improper connection of the equipment grounding
conductor can result in risk of electrical shock.
• Check with a qualifi ed electrician or service provider
if you are in doubt as to whether the equipment is
properly grounded or installed on a dedicated line.
• Seek a qualifi ed electrician to perform any
modifi cations to the cord or plug. TRUE is not
responsible for injuries or damages as a result of
cord or plug modifi cation.
• To reduce the risk of burns, fi re, electric shock, or
injury, it is imperative to connect each product to a
properly grounded 110V or 220V electrical outlet.
The voltage required for your unit is located on the
serial number decal (usually on the front of the unit).
Depending on where you live voltage requirements
diff er.
• Some TRUE products require a circuit rated 110V,
60 Hz, and 20 amps. In the United States, most
residential homes have circuits rated 110V, 60 Hz,
and 15 amps. If your unit requires a 20 amp outlet,
contact an electrician to install a dedicated 20 amp
circuit prior to use.
Power Information
Line Voltage
Model
(V)
110
RC900
220
*The plug confi guration for the power adapter may vary by country.
Rated
Frequency
Current
(Hz)
(Amps)
50/60Hz 20
50/60Hz 15
• 110 Volt—This model is for use on a nominal
110V circuit and has a grounding plug that looks
like the plug illustrated in fi gure A. Make sure the
product is connected to an outlet having the same
confi guration as the plug. No adapter should be
used with this product.
• 220 Volt—This model is for use on a circuit having
a nominal rating no less than 208V and more than
240V and is factory equipped with a specifi c electric
cord and has a grounding plug that looks like the
plug illustrated in fi gure B. Make sure that the
product is connected to an outlet having the same
confi guration as the plug in fi gure B. No adapter
should be used with this product. If the product must
be reconnected for use on a diff erent type of electric
circuit, the reconnection should be made by qualifi ed
service personnel.
FIGURE A
grounded
outlet
grounding pin
Number of Units
Plug/Outlet*
per Circuit
NEMA 5-20
Up to 5 bikes per
circuit—DO NOT
exceed
NEMA 6-15*
Up to 5 bikes per
circuit—DO NOT
exceed
FIGURE B
grounded
outlet
grounding pin
Max Power
Dissipation (Watt)
350 watts per bike
equipped with an
Envision II 16" or
ShowRunner II console
350 watts per bike
equipped with an
Envision II 16" or
ShowRunner II console
