ASSEMBLY STEPS

STEP 1—ATTACH REAR STABILIZER
Tools Used in this Step
8mm Allen Wrench
1. Rotate the bike frame forward on the metal front stabilizer bracket.
NOTE: At least one person should hold the bike frame, while another installs the rear stabilizer.
2. Using a 8mm allen wrench, install the rear stabilizer into the metal bracket using 2 screws, 2 spring washers, and 2
fl at washers.
16
Parts Used in this Step
PART DESCRIPTION
RCS0368 SOCKET HD CAP SCREW, M10
FE0090 WASHER, SPRING, M10
RCS0369 FLAT WASHER, 10MM X 20MM, T=2MM
RB0002BK SUBASSEMBLY, REAR STABILIZER
QTY
2
2
2
1
RB0002BK
RCS0369
FE0090
RCS0368
