Introduction
This section gives an overview of the DTP2 T 203 and its features. Topics include:
•
•
•
•
About this Guide
This user guide contains installation, configuration, and operating information for the
DTP2 T 203.
NOTE: Throughout this guide, the general terms "switcher," "transmitter," and "switching
Product Description
The DTP2 T 203 is a three‑input, multi‑format DTP2 switching transmitter consisting of one
DisplayPort input and two HDMI inputs, one analog audio input, and a DTP/HDBT output.
It switches and extends digital video with resolutions up to 4K @ 60 Hz 4:4:4, analog audio,
bi‑directional RS‑232 and IR over one shielded twisted pair (STP) cable capable of switching
and extending a DTP/HDBT signal up to 330 feet (100 meters).
It is an HDCP compliant switcher, which supports video resolutions up to 4K @ 60 Hz,
including Deep Color, as well as data rates up to 18 Gbps, 3D, Lip Sync, HDCP 2.3, HDBT
compatibility, and HD lossless audio formats. The device also features EDID Minder for
managing EDID, and Key Minder for managing HDCP to DTP, DTP2, and HDBase‑T (HDBT)
receivers.
The switcher features can be integrated into many applications that use a DTP‑equipped
receiver or HDBT‑capable products. The switcher can be remotely powered over the
shielded twisted pair cable by a DTP2‑enabled product. Alternatively, it can be configured
to provide power to a connected DTP2 receiver, allowing both devices to share one power
supply.
The DTP2 T 203 switcher can be controlled via the front panel, the RS‑232 interface,
USB, or LAN. Inputs can be selected by pressing the front panel buttons, enabling
auto‑input switching, entering Simple Instruction Set (SIS) commands, or using
Extron Product Configuration Software (PCS) via LAN or USB.
An internal web page provides system status and some device configuration using a
standard browser.
About this Guide
Product Description
Features
Application Diagram
transmitter" are used interchangeably to refer to the DTP2 T 203.
DTP2 T 203 • Introduction
1
