Introduction
This section gives an overview of the DTP3 T 101 D and its features. Topics include:
•
About this Guide
•
Product Description
•
Features
•
Application Diagram
About this Guide
This user guide contains installation, configuration, and operating information for the DTP3 T 101 D.
NOTE: Throughout this guide, the general term "transmitter" is used to refer to DTP3 T 101 D.
Product Description
The DTP3 T 101 D is a one‑gang decorator‑style transmitter for sending HDMI signals up to 300 feet (100 meters)
over a shielded CATx cable to an Extron DTP‑enabled product. It supports video resolution up to 4096x2160 @
60 Hz at 4:4:4 chroma sampling and complies with HDMI 2.0 and HDCP 2.3. The DTP3 T 101 D provides reliable
transmission of HDMI signals. The one‑gang wall‑mountable design of the DTP3 T 101 D offers the convenience
of placing input connections precisely where they are needed.
Features
•
Transmits HDMI up to 330' (100 m) over a shielded CAT 6A cable — The DTP3 T 101 D provides high
reliability and maximum performance on an economical and easily installed cable infrastructure.
•
Supports computer and video resolutions up to 4K/60 @ 4:4:4 — Support of 4K/60 at 4:4:4 color
sampling requires connection to matching DTP3 products.
•
Comprehensive EDID management — Use PCS software to access EDID Minder for setting video input
EDID, capturing EDID from connected displays, or uploading custom EDID files. Proper EDID management
ensures that sources and displays are easily integrated into a system resulting in optimized system operation.
Freely downloadable EDID Manager software is available for advanced EDID editing and creating custom
EDID files.
•
EDID Minder
Minder ensures that the source powers up properly and reliably outputs content for display.
•
HDCP 2.3 compliant — Ensures display of content‑protected 4K video media and maintains interoperability
with earlier versions of HDCP.
•
Supported HDMI 2.0b specification features include data rates up to 18 Gbps, HDR, Deep Color up to
12‑bit, 3D, HD lossless audio formats, and CEC pass‑through
•
Remote power capability with DTP3 products — For simplified installation, the transmitter can be remotely
powered by a DTP3‑enabled product over the twisted pair connection. It can also be configured to provide
power to a connected DTP3 receiver.
•
Extron XTP DTP 22 shielded twisted pair cable is strongly recommended for optimal performance
•
Compatible with CAT 6A shielded twisted pair cable
•
Support for HDR – High Dynamic Range Video — Enables greater contrast range and wider color gamut
by providing the necessary video bandwidth, color depth, and metadata interchange capability for HDR video.
automatically manages EDID communication between connected devices — EDID
®
