Adjusting The Headphone Volume Level (Headphones Level); Setting The Background Color For Osd (Osd Setup); Switching The Osd Position (Osd Position) - Onkyo TX-NR801 Instruction Manual

Preference (Advanced)—Continued
Adjusting the Headphone Volume
Level (Headphones Level)
If you notice a large difference in the volume when
listening with the headphones than when listening to the
speakers, you can change the headphone volume level so
that you do not have to make adjustments with the main
volume dial each time you put on the headphones.
The headphone volume can be adjusted between –12 and
+12 decibels.
4-2.HeadphoneLevel
a.Headphones Level
Setting the Background Color for
OSD (OSD Setup)
This sub-menu allows you to customize the OSD Setup
Menu to display in the manner you desire.
USA, Canadian
and Australian models
4-3.OSD Setup
a.Background Color
:Blue1
b.Superimpose Mode
:OSD On
c.Immediate Display
:On
d.Display Position
:Bottom
Quit:[SETUP]
a. Background Color
Select either Blue1, Blue2, Green1, Green2, Magenta,
Red1, or Red2 as the background color when the OSD
Setup Menu is displayed.
b. Superimpose Mode
(USA, Canadian and Australian models)
Off: Select to have the OSD Setup Menu displayed
on the selected background color. If this is set to
"Off," the background color will not be displayed
even when there is no video signal input.
Normal: Select to have the OSD Setup Menu super-
imposed over the current video if one is displayed or
on the selected background color if there is no video
signal.
Black: Select to have the OSD Setup Menu dis-
played on a black background at all times.
: 0dB
Quit:[SETUP]
Other models whose
TV format is PAL
4-3.OSD Setup
a.Background Color
:Blue1
b.Component Video
:OSD On
c.Immediate Display
:On
d.Display Position
:Bottom
Quit:[SETUP]
b. Component Video
(Other models whose TV format is PAL)
You can select whether the OSD signal is output to
the TV monitor connected to the COMPONENT
VIDEO connectors or not.
OSD On: The OSD signal is output.
OSD Off: The OSD signal is not output.
c. Immediate Display
On: Select to have the screen immediately display
certain operations as you perform them (e.g., having
the input source displayed whenever an input source
selector button is pressed). The display will remain
for five seconds after the operation is completed.
Off: Select to turn off the immediate display of oper-
ations.
Note (When the model is for USA, Canada or Austra-
lia and its TV format is PAL):
While the component video signal is output and even
when this setting is set to "On," the information on the
Immediate Display will not be displayed.
d. Display Position
Use this setting to select the position of the immediate
display that appears when certain operations are
performed. You can position the immediate display at
any of ten different levels ranging from the top all the
way to the bottom.
Switching the OSD Position
(OSD Position)
This sub-menu allows you to adjust the position of the
OSD Setup Menu as it is displayed on your screen.
Depending on the monitor used, there may be cases
where the OSD Setup Menu is not displayed in the
center and parts of the menus are cut off. To adjust the
position of the OSD Setup Menu, simply press the cursor
buttons to inch the menu to the position you desire.
4-4.OSD Position
Exit:[RETURN]
VIDEO 1
63
